Table 3-5. Configuring Modules (continued)
Attachment
Module Type
UTP Dual
Dual homing
Single
Null
To change the configuration of the attachment ports, follow these steps:
1. Enter the set attach command. Type:
set attach
This selection prompt appears:
Select one of the following:
1. B/A
2. S/M
3. M/M
Attachment port configuration?
2. Select the attachment port configuration that you want. For example,
type:
2 [Enter]
These confirmation lines appear:
Current configuration:
Initialize attachment as:
When you reset the hub, the attachment ports will be configured as S/M.
Configuring the Hub
Attachment Additional
Port Equipment
Configuration Required
B/A Cross-over cable
B/A Cross-over cable
S/M Cross-over cable
M/M Cross-over cable
B/A
S/M
3-17
