Using the Output Stacker

The Output Stacker can be used in two positions, as shown.
Regular position
Extended position
Use the Output Stacker in the normal position.
For some types of media, you can use the stacker in the extended position. Squeeze the wires of Basket Wire
#2 (a) and pull them toward the front (b). Peel off the Velcro Tape (c) of the Basket Band and fasten it in
the middle of Basket Rod #2 (d) to put the stacker in the extended position. This position enables printed
documents to be removed more easily.
For information on the position for easy removal, refer to the Paper Reference Guide. (→P.107)
Important
•
The Output Stacker can hold one sheet. When printing multiple pages, remove each sheet after it
is printed.
Output Stacker
Handling Paper 201
