2.
Press the Menu button to display MAIN MENU.
3.
Press ◄ or ► to select Adjust Printer, and then press ▼.
4.
Press ◄ or ► to select Adjust Length, and then press ▼.
5.
Press ◄ or ► to select Yes, and then press the OK button.
The setting is updated, and an equals sign "=" is displayed at left.
A test pattern is printed for adjustment based on the amount of paper stretching or shrinkage.
The scale bar shows "Millimeter" in 50 mm units and "Inch" in 1 inch units.
6.
Measure the length of the adjustment pattern. Calculate the difference between the measured
length and actual length. Enter it as a percentage and press the OK button.
You can adjust the value in 0.02% increments. Press ◄ to increase the value and ► to decrease
it.
If the scale is printed shorter than actual size, set the value toward the positive side; if it is printed
longer, set the value toward the negative side.
The setting for the amount of paper stretching or shrinkage is relative. If you access it again
later, it will be displayed as 0.00%.
Note
•
You can also specify the adjustment value by selecting Adjust Length in Med.Detail Set..
MAIN MENU
Adjust Printer ↓
Adjust Printer
Adjust Length ↓
Adjust Length
= Yes
Adjust Length
=0.02%
Adjusting the feed amount
Maintenance 625
