Printing Line Drawings and Text (Windows)
This topic describes how to print line drawings based on the following example.
•
Document: CAD drawing
•
Page size: A3 (297.0×420.0 mm [11.7 × 16.5 in])
•
Paper: Sheets ( Cassette )
•
Paper type: Plain Paper
•
Paper size: A3 (297.0×420.0 mm [11.7 × 16.5 in])
1.
Choose Print in the application menu.
2.
Select the printer in the dialog box, and then display the printer driver dialog box. (→P.497)
3.
Make sure the Main sheet is displayed.
4.
A
In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper.
5.
After conrming that
Target list.
Note
•
You can check the settings values selected in the
D
Easy Settings is selected, click CAD (Line Drawing) in the
E
Print Target list by clicking
Printing CAD Drawings
E
Print
F
View Settings.
Enhanced Printing Options 439
