2.
Press the Menu button to display MAIN MENU.
3.
Press ◄ or ► to select Adjust Printer, and then press ▼.
4.
Press the ◄ or ► button to select Auto Head Adj., and then press ▼.
5.
Press ◄ or ► to select Advanced Adj., and then press ▼.
6.
Press ◄ or ► to select Yes, and then press OK.
The setting is updated, and an equals sign "=" is displayed at left.
A test pattern is printed for printhead adjustment.
After reading the pattern, the printer automatically adjusts the Printhead alignment.
Note
•
If paper is fed automatically and no roll is loaded, select the media source and click the OK button.
MAIN MENU
Adjust Printer ↓
Adjust Printer
Auto Head Adj. ↓
Auto Head Adj.
Advanced Adj. ↓
Advanced Adj.
= Yes
