Adjusting the feed amount
2.
Press the Menu button to display MAIN MENU.
3.
Press ◄ or ► to select Adjust Printer, and then press the ▼ button.
4.
Press ◄ or ► to select Manual Band Adj, and then press the ▼ button.
5.
Press ◄ or ► to select Yes, and then press the OK button.
The setting is updated, and an equals sign "=" is displayed at left.
Test pattern A is printed for band adjustment.
6.
Examine test pattern A for band adjustment. After you determine the pattern in which streaks are
least noticeable, press ◄ or ► to choose the pattern number, and then press the OK button.
Test pattern B is printed for band adjustment.
Note
•
If streaks seem least noticeable in two patterns but you cannot decide which one is better, choose an
intermediate value. For example, choose 11 if you cannot decide whether pattern 10 or 12 is better.
620 Maintenance
MAIN MENU
Adjust Printer ↓
Adjust Printer
Manual Band Adj ↓
Manual Band Adj
= Yes
Adj.Setting
=8
