Adjusting the Printhead

Adjusting the Printhead Height

If paper rubs against the printer or the edge is wrinkled from rubbing, adjusting the Printhead height may
improve results.
1.
Press the Menu button to display MAIN MENU.
2.
Press ◄ or ► to select Med.Detail Set., and then press ▼.
3.
Press ◄ or ► to select the type of paper, and then press ▼.
4.
Press ◄ or ► to select Head Height, and then press ▼.
5.
Press ◄ or ► to select Printhead, and then press the OK button.
The setting is updated, and an equals sign "=" is displayed at left.
Important
If you switch to another type of paper after printing, reset the Printhead height to Automatic.
614 Maintenance
MAIN MENU
Med.Detail Set. ↓
Med.Detail Set.
Plain Paper ↓
Plain Paper
Head Height ↓
Head Height
= Automatic
