Installing The Processor; Figure 23. Lifting The Processor Socket Handle; Figure 24. Installing The Processor - Intel SR1560SF - Server System - 0 MB RAM Service Manual

Installing the Processor

1. Locate the processor socket and raise the socket handle completely (see
2. Raise the CPU load plate (see
Note: Do not touch the socket pins; they are very sensitive and easily damaged.
28

Figure 23. Lifting the Processor Socket Handle

Figure
A

Figure 24. Installing the Processor

TP02074
24).
B
®
Intel Server System SR1560SF Service Guide
Figure 23).
TP02075
