4. Wait five seconds.
5. Return the CMOS Clear jumper to the CMOS Protect location, covering pins 1 and
2.
6. Close the server chassis.
7. Power up the system.
8. The CMOS is now cleared and can be reset by going into the BIOS setup.

Resetting the Password

If the user or administrator password(s) is lost or forgotten, moving the password reset
jumper into the "clear" position clears both passwords. The password reset jumper must
be restored to its original position before a new password(s) can be set.
1. Power down the system; do not disconnect the AC power.
2. Open the server system.
3. Move the jumper from the normal operation position, Password Clear Protect, at
pins 1 and 2 to the Password Clear Erase position, covering pins 2 and 3.
4. Wait five seconds.
5. Return the Password Reset jumper to the Password Clear Protect position, covering
pins 1 and 2.
6. Close the server system.
7. Power up the server.
8. The password is now cleared and can be reset by going into BIOS setup.
®
Intel Server System SR1560SF Service Guide
BMC Force
Update Mode
2 2
Password
Reset
3 3
2
CMOS
Clear
3

Figure 68. Password Reset Jumper

Disable
Enable
AF002170
63
