Intel Server System SR1560SF Service Guide
®
Table 2. Intel Server System SR1560SF Feature Summary
Feature
®
Intel
Ethernet LAN connectivity
•
One PCI Express* x16 GEN2 add-in card slot
•
Fixed drive system:
–
•
Hot-swap drive system:
–
•
Intel
levels 0/1/10
•
Optional support for SW RAID 5 with enablement key
•
Slimline bay for IDE optical drive
•
Optional USB floppy drive (product code SR1560SFHS)
•
Standard control panel
With standard control panel:
•
NIC1 Activity
•
NIC2 Activity
•
Power / Sleep
•
System Status
•
System Identification
•
Hard Drive Activity
Internal light guided diagnostics:
•
Fan Fault
•
Memory Fault
•
CPU Fault
•
5VSB
•
System Status
•
System Identification
Single 600 W power supply
•
Five non-redundant, monitored and controlled system fans
•
Two non-redundant fans in power supply
•
One front panel USB 2.0 port
•
Two back I/O USB 2.0 ports
®
Intel
Description
82563EB dual port controller for 10/100/1000 Mbit/sec
Two SATA drives
Three SATA/SAS drives
®
Embedded Server RAID Technology II with SW RAID
System Management Software
5
