Platform Installations and Upgrades
CAUTION
Press the riser card straight down into the slot. Press down on the riser card,
not on the PCI card. Tipping it in the slot while installing it or pressing on
the PCI card may damage the riser card, board slot, or the PCI card.
8. Firmly press the riser card straight down until it is seated in the server board slot.
9. Replace the screw that attaches the riser assembly to the chassis.
A

Figure 31. Replacing a Riser Card

B
TP00586
B
47
