Port-based port mirroring

Command: /cfg/pmirr/monport <port number>
[Port 1 Menu]
The following table describes the port-based Port Mirroring Configuration Menu options.
Table 176 Port Mirroring Configuration Menu options
Command
add <mirrored port> in|out|both
rem <mirrored port>
delete
cur

Uplink Failure Detection configuration

Command: /cfg/ufd
[Uplink Failure Detection Menu]
Uplink Failure Detection (UFD) supports network fault tolerance in network adapter teams. Use this menu to configure
a Failure Detection Pair of one Links to Monitor (LtM) group and one Links to Disable (LtD) group. When UFD is
enabled and a Failure Detection Pair is configured, the switch automatically disables ports in the LtD if it detects a
failure in the LtM. The failure conditions which are monitored in the LtM group include port link state moving to down,
or port state moving to Blocking if Spanning Tree Protocol is enabled.
The following table describes the Uplink Failure Detection (UFD) Configuration Menu options.
Table 177 Uplink Failure Detection Configuration Menu options
Command
fdp
on
off
cur
add - Add "Mirrored" port
rem - Rem "Mirrored" port
delete - Delete this "Monitor" port
cur - Display current Port-based Port Mirroring configuration
fdp - Failure Detection Pair Menu
on - Globally turn Uplink Failure Detection ON
off - Globally turn Uplink Failure Detection OFF
cur - Display current Uplink Failure Detection configuration
Description
Displays the Failure Detection Pair menu.
Globally turns Uplink Failure Detection ON.
Globally turns Uplink Failure Detection OFF.
Displays the current Uplink Failure Detection configuration parameters.
Description
Adds the port to be mirrored. This command also allows you to enter the
direction of the traffic. It is necessary to specify the direction because:
If the source port of the frame matches the mirrored port and the
mirrored direction is ingress or both (ingress and egress), the frame
is sent to the mirrored port.
If the destination port of the frame matches the mirrored port and
the mirrored direction is egress or both, the frame is sent to the
monitoring port.
Removes the mirrored port.
Deletes this monitored port.
Displays the current settings of the monitoring port.
Configuration Menu 156
