Table 18
Layer 2 Information Menu options
Command
trunk
vlan
gen
dump
FDB information menu
Command: /info/l2/fdb
[Forwarding Database Menu]
The forwarding database (FDB) contains information that maps the media access control (MAC) address of each
known device to the switch port where the device address was learned. The FDB also shows which other ports have
seen frames destined for a particular MAC address.
NOTE:
The master forwarding database supports up to 8K MAC address entries on the management processor
(MP) per switch.
Table 19
FDB information menu /info/l2/fdb
find <MAC address> [<VLAN>]
port <port number>
vlan <1-4095>
state unknown|ignore|
forward|flood|trunk|ifmac
dump
Usage
When trunk groups are configured, you can view the state of each port in
the various trunk groups.
Displays VLAN configuration information, including:
Displays general Layer 2 configuration information.
Dumps all switch information available from the Layer 2 menu (10K or more,
depending on your configuration).
If you want to capture dump data to a file, set your communication software
on your workstation to capture session data prior to issuing the dump
commands.
find
- Show a single FDB entry by MAC address
port
- Show FDB entries on a single port
vlan
- Show FDB entries on a single VLAN
state
- Show FDB entries by state
dump
- Show all FDB entries
VLAN Number
VLAN Name
Status
Port membership of the VLAN
Displays a single database entry by its MAC address. You are prompted
to enter the MAC address of the device.
Enter the MAC address using the format: xx:xx:xx:xx:xx:xx. (For
example: 08:00:20:12:34:56)
You can also enter the MAC address using the format: xxxxxxxxxxxx.
(For example: 080020123456)
Displays all FDB entries for a particular port.
Displays all FDB entries on a single VLAN. The range is 1-4095.
Displays all FDB entries that match a particular state.
Displays all entries in the Forwarding Database.
Information Menu 33
