Failure Detection Pair configuration

Command: /cfg/ufd/fdp
[FDP Menu]
Use these commands to configure a Failure Detection Pair, which consists of one Link to Monitor (LtM) and one Link to
Disable (LtD). When the switch detects a failure on the LtM, it automatically disables the ports in the LtD.
The following table describes the Failure Detection Pair (FDP) configuration Menu options.
Table 178 Failure Detection Pair Configuration Menu options
Command
ltm
ltd
ena
dis
current

Link to Monitor configuration

Command: /cfg/ufd/fdp/ltm
[Failure Link to Monitor Menu]
The following table describes the Link to Monitor (LtM) Menu options. The LtM can consist of only one uplink port
(ports 20-24) or a single trunk containing only uplink ports.
Table 179 Link to Monitor Menu options
Command
addport <port number>
remport <port number>
addtrnk <1-12>
remtrnk <1-12>
cur
ltm - Link to Monitor Menu
ltd - Link to Disable Menu
ena - Enable FDP
dis - Disable FDP
current - Display current FDP configuration
Description
Displays the Links to Monitor menu.
Displays the Links to Disable menu.
Enables the FDP Parameters.
Disables the FDP Parameters.
Displays the current FDP configuration.
addport - Add port to Link to Monitor
remport - Remove port from Link to Monitor
addtrnk - Add trunk to Link to Monitor
remtrnk - Remove trunk from Link to Monitor
cur - Display current LtM configuration
Description
Adds a port to the LtM. Only uplink ports (20-24) are allowed in the LtM.
Removes a port from the LtM.
Adds a trunk group to the LtM. The LtM trunk group can contain only uplink ports
(20-24).
Removes a trunk group from the LtM.
Displays the current LtM configuration.
Configuration Menu 157
