ARP information

Command: /info/arp
[Address Resolution Protocol Menu]
The Address Resolution Protocol (ARP) information includes IP address and MAC address of each entry, address status
flags, VLAN, and port for the address, and port referencing information.
The following table describes the Address Resolution Protocol Menu options.
Table 30 ARP information
Command
find <IP address>
port <port number>
vlan <1-4095>
dump
addr

Show all ARP entry information

Command: /info/arp/dump
IP address
--------------- -----
192.168.2.4
192.168.2.19
192.168.2.61
The Flag field provides additional information about an entry. If no flag displays, the entry is normal.
Table 31 ARP dump flag parameters
Flag
P
R
U

ARP address list information

Command: /info/arp/addr
IP address
--------------- ---------------
205.178.18.66
205.178.50.1
205.178.18.64
This screen displays all entries in the ARP cache.
find - Show a single ARP entry by IP address
port - Show ARP entries on a single port
vlan - Show ARP entries on a single VLAN
dump - Show all ARP entries
addr - Show ARP address list
Usage
Displays a single ARP entry by IP address. For example, 192.4.17.101
Displays the ARP entries on a single port.
Displays the ARP entries on a single VLAN.
Displays all ARP entries, including:
IP address and MAC address of each entry
Address status flag
The VLAN and port to which the address belongs
The ports which have referenced the address (empty if no port has routed traffic to
the IP address shown)
Displays the ARP address list: IP address, IP mask, MAC address, and VLAN flags.
Flags
P
Description
Permanent entry created for switch IP interface.
Indirect route entry.
Unresolved ARP entry. The MAC address has not been learned.
IP mask
255.255.255.255
255.255.255.255
255.255.255.255
MAC address
-----------------
00:50:8b:b2:32:cb
00:0e:7f:25:89:b5
00:0f:6a:ed:46:00
MAC address
----------------- ---- -----
00:70:cf:03:20:04
00:70:cf:03:20:06
00:70:cf:03:20:05
VLAN Port
---- ----
1 18
1 17
1
VLAN Flags
P
1
1
Information Menu 46
