virtual router ID and an IP address. On each VRRP-capable routing device participating in redundancy for this virtual
router, a virtual router will be configured to share the same virtual router ID and IP address.
The following table describes the Virtual Router Group Configuration Menu options.
Table 153 Virtual Router Group Configuration Menu options
Command
track
vrid <1-255>
if <1-256>
prio <1-254>
adver <1-255>
preem disable|enable
ena
dis
del
cur

VRRP Virtual Router Group Priority Tracking configuration

Command: /cfg/l3/vrrp/group/track
[Virtual Router Group Priority Tracking Menu]
ifs
ports
cur
NOTE: If Virtual Router Group Tracking is enabled, then the tracking option will be available only under group
option. The tracking setting for the other individual virtual routers will be ignored.
Description
Displays the VRRP Priority Tracking Menu for the virtual router group. Tracking
is a proprietary extension to VRRP, used for modifying the standard priority
system used for electing the master router.
Defines the virtual router ID.
The for standard virtual routers (where the virtual router IP address is not
vrid
the same as any virtual server) can be any integer between 1 and 255. All
values must be unique within the VLAN to which the virtual router's IP
vrid
interface (see
if
Selects a switch IP interface. The default switch IP interface number is 1.
Defines the election priority bias for this virtual router group. This can be any
integer between 1 and 254. The default value is 100.
During the master router election process, the routing device with the highest
virtual router priority number wins. If there is a tie, the device with the highest IP
interface address wins. If this virtual router's IP address (
the one used by the IP interface, the priority for this virtual router will
automatically be set to 255 (highest).
When priority tracking is used (
/cfg/l3/vrrp/vr #/track
according to a number of performance and operational criteria.
Defines the time interval between VRRP master advertisements. This can be any
integer between 1 and 255 seconds. The default is 1.
Enables or disables master preemption. When enabled, if the virtual router
group is in backup mode but has a higher priority than the current master, this
virtual router will preempt the lower priority master and assume control. Note
that even when
preem
other master if this switch is the owner (the IP interface address and virtual
router are the same). By default, this option is enabled.
addr
Enables the virtual router group.
Disables the virtual router group.
Deletes the virtual router group from the switch configuration.
Displays the current configuration information for the virtual router group.
- Enable/disable tracking other interfaces
- Enable/disable tracking VLAN switch ports
- Display current VRRP Group Tracking configuration
below) belongs. The default virtual router ID is 1.
/cfg/l3/vrrp/track or
), this base priority value can be modified
is disabled, this virtual router will always preempt any
) is the same as
addr
Configuration Menu 144
