Route Statistics; Arp Statistics - HP GbE2c - Blc Layer 2/3 Fiber SFP Option Command Reference Manual

Table 57 IP statistics
Statistics
ipInAddrErrors
ipInUnknownProtos
ipInDiscards
ipInDelivers
ipOutRequests
ipOutDiscards
ipDefaultTTL

Route statistics

Command: /stats/l3/route
Route statistics:
ipRoutesCur:
ipRoutesMax:
The following table describes the Route statistics:
Table 58 Route statistics
Statistics
ipRoutesCur
ipRoutesMax
ipRoutesHighWater

ARP statistics

Command: /stats/l3/arp
ARP statistics:
arpEntriesCur:
Description
The number of input datagrams discarded because the IP address in their IP header
destination field was not a valid address to be received at this switch. This count includes
invalid addresses (for example, 0.0.0.0) and addresses of unsupported classes (for
example, Class E).
For entities which are not IP gateways and therefore do not forward datagrams, this
counter includes datagrams discarded because the destination address was not a local
address.
The number of locally addressed datagrams received successfully but discarded because
of an unknown or unsupported protocol.
The number of input IP datagrams for which no problems were encountered to prevent
their continued processing, but which were discarded (for example, for lack of buffer
space).
This counter does not include any datagrams discarded while awaiting re-assembly.
The total number of input datagrams successfully delivered to IP user-protocols (including
ICMP).
The total number of IP datagrams that local IP user-protocols (including ICMP) supplied to
IP in requests for transmission.
This counter does not include any datagrams counted in ipForwDatagrams.
The number of output IP datagrams for which no problem was encountered to prevent
their transmission to their destination, but which were discarded (for example, for lack of
buffer space).
This counter would include datagrams counted in ipForwDatagrams if any such packets
met this (discretionary) discard criterion.
The default value inserted into the Time-To-Live (TTL) field of the IP header of datagrams
originated at this switch, whenever a TTL value is not supplied by the transport layer
protocol.
7 ipRoutesHighWater:
4096
Description
The total number of outstanding routes in the route table.
The maximum number of supported routes.
The highest number of routes ever recorded in the route table.
2 arpEntriesHighWater:
7
4
Statistics Menu 73
