Table 66
OSPF global statistics
Statistic
Timers Kickoff:
hello
retransmit
lsa lock
lsa ack
dbage
summary
ase export
VRRP statistics
Virtual Router Redundancy Protocol (VRRP) support on the GbE2c provides redundancy between routers in a LAN.
This is accomplished by configuring the same virtual router IP address and ID number on each participating VRRP-
capable routing device.
One of the virtual routers is then elected as the master, based on a number of priority criteria, and assumes control of
the shared virtual router IP address. If the master fails, one of the backup virtual routers will assume routing authority
and take control of the virtual router IP address.
When virtual routers are configured, you can display the following protocol statistics for VRRP:
Advertisements received (vrrpInAdvers)
Advertisements transmitted (vrrpOutAdvers)
Advertisements received, but ignored (vrrpBadAdvers)
NOTE:
VRRP commands are available only on the GbE2c Layer 2/3 Ethernet Blade Switch.
Command: /stats/l3/vrrp
>> Layer 3 Statistics# vrrp
VRRP statistics:
vrrpInAdvers:
vrrpOutAdvers:
vrrpBadVersion:
vrrpBadAddress:
vrrpBadPassword:
The following table describes the VRRP statistics.
Table 67
VRRP statistics
Field
vrrpInAdvers
vrrpOutAdvers
vrrpBadVersion
vrrpBadAddress
vrrpBadPassword
vrrpBadAdvers
vrrpBadVrid
vrrpBadData
Description
The sum total number of times the Hello timer has been fired (which triggers the
of a Hello packet) across all OPSF areas and interfaces.
send
The sum total number of times the Retransmit timer has been fired across all OPSF
areas and interfaces.
The sum total number of times the Link State Advertisement (LSA) lock timer has been
fired across all OSPF areas and interfaces.
The sum total number of times the LSA
areas and interfaces.
The total number of times the data base age (Dbage) has been fired.
The total number of times the Summary timer has been fired.
The total number of times the Autonomous System Export (ASE) timer has been fired.
0
vrrpBadAdvers:
0
0
vrrpBadVrid:
0
vrrpBadData:
0
vrrpBadInterval:
Description
The total number of VRRP advertisements that have been received.
The total number of VRRP advertisements that have been sent.
The total number of VRRP advertisements that had a bad version number.
The total number of VRRP advertisements that had a bad address.
The total number of VRRP advertisements that had a bad password.
The total number of VRRP advertisements received that were dropped.
The total number of VRRP advertisements that had a bad virtual router ID.
The total number of VRRP advertisements that had bad data.
timer has been fired across all OSPF
Ack
0
0
0
0
Statistics Menu 80
