Command line interface
Introduction
The HP GbE2c switch is ready to perform basic switching functions right out of the box. Some of the more advanced
features, however, require some administrative configuration before they can be used effectively. This guide provides
a command reference for the HP GbE2c Ethernet Blade Switch and the HP GbE2c Layer 2/3 Ethernet Blade Switch.
The extensive switching software included in the switch provides a variety of options for accessing and configuring
the switch:
Built-in, text-based command line interfaces (AOS CLI and ISCLI) for access via a local terminal or remote
Telnet/Secure Shell (SSH) session
Simple Network Management Protocol (SNMP) support for access through network management software such
as HP Systems Insight Manager
A browser-based management interface for interactive network access through the Web browser
The command line interface provides a direct method for collecting switch information and performing switch
configuration. Using a basic terminal, you can view information and statistics about the switch, and perform any
necessary configuration.
This chapter explains how to access the AOS CLI to the switch.

Additional references

Additional information about installing and configuring the switch is available in the following guides, which are
available at http://www.hp.com/go/bladesystem/documentation.
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem User Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem ISCLI Reference Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Application Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Browser-based Interface Reference Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Quick Setup Instructions

Connecting to the switch

You can access the command line interface in one of the following ways:
Using a console connection via the console port
Using a Telnet connection over the network
Using a Secure Shell (SSH) connection to securely log in over a network

Establishing a console connection

To establish a console connection with the switch, you need:
A null modem cable with a female DB-9 connector (See the HP GbE2c Ethernet Blade Switch for c-Class
BladeSystem User Guide for more information.)
An ASCII terminal or a computer running terminal emulation software set to the parameters shown in the table
below
Table 1 Console configuration parameters
Parameter
Baud Rate
Data Bits
Parity
Stop Bits
Flow Control
Value
9600
8
None
1
None
Command line interface 9
