ACL Re-mark In-Profile configuration

Command: /cfg/acl/acl <1-762>/re-mark/inprof
[Re-marking - In Profile Menu]
up1p
updscp
reset
cur
Table 166 ACL Re-mark In-Profile Configuration Menu options
Command
up1p
updscp <0-63>
reset
cur

ACL Re-mark In-Profile Update User Priority configuration

Command: /cfg/acl/acl <1-762>/re-mark/inprof/up1p
[Update User Priority Menu]
value
utosp
reset
cur
Table 167 ACL Update User Priority Configuration Menu options
Command
value <0-7>
utosp enable|disable
reset
cur

ACL Re-mark Out-of-Profile configuration

Command: /cfg/acl/acl <1-762>/re-mark/outprof
[Re-marking - Out Of Profile Menu]
updscp
reset
cur
Table 168 ACL Re-mark Out-of-Profile Configuration Menu options
Command
updscp <0-63>
reset
cur
- Set Update User Priority Menu
- Set the update DSCP
- Reset in profile settings
- Display current settings
Description
Displays the Re-Mark In-Profile Update User Priority Menu.
Sets the DiffServ Code Point (DSCP) of In-Profile packets to the selected value.
Resets the update DSCP parameters to their default values.
Displays the current ACL re-mark in-profile parameters.
- Set the update user priority
- Enable/Disable use of TOS precedence
- Reset in profile up1p settings
- Display current settings
Description
Defines 802.1p value. The value is the priority bits information in the packet
structure.
Enable or disable mapping of TOS (Type of Service) priority to 802.1p priority
for In-Profile packets. When enabled, the TOS value is used to set the 802.1p
value.
Resets UP1P settings to their default values.
Displays the current ACL Update User Priority parameters.
- Set the update DSCP
- Reset out of profile settings
- Display current settings
Description
Sets the DiffServ Code Point (DSCP) of Out-of-Profile packets to the selected
value. The switch sets the DSCP value on Out-of-Profile packets.
Resets the update DSCP parameters for Out-of-Profile packets to their default
values.
Displays the current ACL re-mark out-profile parameters.
Configuration Menu 151
