NOTE: These priority tracking options only define increment values. These options do not affect the VRRP
master router election process until options under the VRRP Virtual Router Priority Tracking Menu are enabled.
The following table describes the VRRP Tracking Configuration Menu options.
Table 156 VRRP Tracking Configuration Menu options
Command
vrs <0-254>
ifs <0-254>
ports <0-254>
cur

Quality of Service configuration

Command: /cfg/qos
[QOS Menu]
8021p
Use the Quality of Service (QoS) menus to configure the IEEE 802.1p priority value of incoming packets. This allows
you to differentiate between various types of traffic, and provide different priority levels. The following table describes
the QoS Configuration Menu options.
Table 157 QoS Configuration Menu options
Command
8021p

QoS 802.1p configuration

Command: /cfg/qos/8021p
[802.1p Menu]
priq
qweight
cur
This feature provides the GbE2c the capability to filter IP packets based on the IEEE 802.1p bits in the packet's VLAN
header. The 802.1p bits specify the priority that you should give to the packets while forwarding them. The packets
with a higher (non-zero) priority bits are given forwarding preference over packets with numerically lower priority bits
value.
The following table describes the 802.1p Configuration Menu options.
Table 158 802.1p Configuration Menu options
Command
priq <0-7> <0-1>
qweight <0-1> <0-15>
cur

Access Control configuration

Command: /cfg/acl
Description
Defines the priority increment value (0 through 254) for virtual routers in master
mode detected on this switch. The default value is 2.
Defines the priority increment value (0 through 254) for active IP interfaces
detected on this switch. The default value is 2.
Defines the priority increment value (0 through 254) for active ports on the
virtual router's VLAN. The default value is 2.
Displays the current configuration of priority tracking increment values.
- 802.1p Menu
Description
Displays 802.1p configuration menu.
- Set priority to COS queue mapping
- Set weight to a COS queue
- Display current 802.1p configuration
Description
Maps the 802.1p priority of to the Class of Service queue (COSq) priority.
Enter the 802.1p priority value (0-7); followed by the Class of Service queue
(0-1) that handles the matching traffic.
Configures the weight of the selected Class of Service queue (COSq). Enter the
queue number (0-1), followed by the scheduling weight (0-15).
Displays the current 802.1p parameters.
