Quasonix TIMTER Installation And Operation Manual page 95

Requirement
CE101 Conducted Emissions, Audio Frequency Currents, Power Leads
CE102 Conducted Emissions, Radio Frequency Potentials, Power Leads
CE106 Conducted Emissions, Antenna Port
CS101 Conducted Susceptibility, Power Leads
CS114 Conducted Susceptibility, Bulk Cable Injection
CS115 Conducted Susceptibility, Bulk Cable Injection, Impulse Excitation
CS116 Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
RE101 Radiated Emissions, Magnetic Field
RE102 Radiated Emissions, Electric Field
RS101 Radiated Susceptibility, Magnetic Field
RS103 Radiated Susceptibility, Electric Field
Quasonix transmitters have been tested for compliance with these standards approximately annually since 2004.
However, such testing is only performed as part of a qualification program, and the test results are the exclusive
property of the customer who paid for them. If you need EMI testing on a particular part number, please contact
sales@quasonix.com for a quote.
6.4 Carrier Frequency Tuning
The carrier frequency is selectable in 0.5 MHz steps, except for units with the FO (frequency offset) option.
Frequencies supported by TIMTER™ Dual Transmitters are listed in Table 16. For higher power requirements,
contact Quasonix.
Band ID Band
Code
A Lower S
B Mid C and Euro Mid C
C "Low"
C
D C (with Mid C)
87 Quasonix, Inc.
Table 15: TIMTER™ EMI Compliance
Description
Table 16: Carrier Frequencies (MHz)
Minimum Maximum
Freq Freq
2200.5 MHz 2300.5 MHz
5091.0 MHz 5150.0 MHz
5150.0 MHz 5250.0 MHz
4400.0 MHz 4950.0 MHz
4400.0 MHz 4950.0 MHz
and and
5091.0 MHz 5150.0 MHz
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Default Freq Tuning
Steps
2250.5 MHz 0.5 MHz
5120.0 MHz 0.5 MHz
4620.0 MHz 0.5 MHz
4620.0 MHz 0.5 MHz
Max
Power
10 W
10 W
10 W
10 W
