Mnemonic
Name
Command
BT
Baseband
Interface Type
CC
Convolutional
Encoder
37
Quasonix, Inc.
Description
Report or set baseband interface
type
Clock and data interfaces are set
to either TTL or RS-422. Clock
interface and data interface are
always the same type.
Examples:
BT
Report the baseband
interface type
BT T
Set the baseband type to
TTL single ended, bias 1.65V
BT R
Set the baseband type to
RS-422 differential input
Refer to section 4.2.3.1.4 for
related BT command detail.
Refer to Table 3 for Clock/Data
Interface codes.
Enables or disables the
convolutional encoder
Examples
CC
Report convolutional
encoder state
CC 0
Set the convolutional
encoder to Disabled
CC 1
Set the convolutional
encoder to Enabled
Refer to section 4.2.3.1.5 for
additional CC command detail
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Setting
Required
Saved?
Clock and
Y
Data
Interface
code D, M,
or S
CE
Y
Factory
Default
BT R
CC 0
