Quasonix Dual Transmitter
TX Serial Number = 1001
Customer Name = Quasonix Customer
Contract Number = 999999-9
Customer Part Number = QSX-VER-111-10S-20-PKG-VP-CF-STC-LD6-CE-THS-SBS-DSWBX-D2
Quasonix Inc.
6025 Schumacher Park Drive
West Chester, OH 45069
(513) 942-1287
www.Quasonix.com
CAGE CODE: 3CJA9
FPGA HW Type: DTX/STC
FPGA version: 000h 01ah
FPGA Build: 0x600F2E90 =
Firmware version: DTX V2.041 4/5/2021
Preset 0 read
3>PA 2 signon
3>PA 1 signon
3>DTXIB signon
3>
3>Ready for Commands
3>RF on/off pin changed from 0 to 1
3>BB clock rate chan 1 out of limits (clk =
3>BB clock rate chan 2 out of limits (clk =
3>Gen 2 Switchbox signon
3>Switchbox Startup Setup sent, reading switchbox
3>Switchbox setup done
3>SWBX Chan 1 Modulation set to PCMFM
3>>SWBX Chan 1, Freq set to 1450.5 MHz
3>>SWBX Chan 2 Modulation set to PCMFM
3>>SWBX Chan 2, Freq set to 1450.5 MHz
3>>
3>
Note: The V1.xxx Dual Transmitter software, displays the current channel and mode as part of the prompt, such as
3_SOQPSK>. If the Dual Transmitter is running V2.xxx, only the current channel displays, such as 2> for Channel
2. All Dual Transmitters running with the CP07 (C7) option display only the current channel as part of the prompt.
4.2.1 Frequency Notes
•
Channel 1 and Channel 2 can use the same source data and frequency.
•
Frequency control is available only via the serial port in the 2 x 3 inch dual transmitter. The 4 x 3 dual
transmitter also supports the new 2
nd
4.2.2 2 Generation Switch Box Notes
nd
If a Quasonix 2 Generation Digital Switch Box is attached to the dual transmitter, and the digital switch box option
is present (check the part/model number of the transmitter for DSWBX), all changes made to mode, frequency, or
LDPC selections on the dual transmitter are also updated immediately on the Switch Box. This ensures the switch
box settings always match those of the transmitter.
32 Quasonix, Inc.
Jan 25 2021 20:48:16
Figure 28: TIMTER™ Welcome Message
nd
Generation Switch Box for setting frequency and mode.
TIMTER™ Multi-mode Dual
Telemetry Transmitter
0.000000 Mbps, src = Ext Clk)
0.000000 Mbps, src = Ext Clk)
