Mnemonic
Name
Command
BBCK
Check BB Clock
BD
Send bias
display
BPV
Binary Protocol
Version
BR
Bit Rate
36
Quasonix, Inc.
Description
Displays the current baseband
clock value and source for each
channel
Example:
1_D2>>BBCK
BB clock rate chan 1 =
5.000010 Mbps, src = Int
Clk C1
BB clock rate chan 2 =
0.999998 Mbps, src = Int
Clk C2
Refer to section 4.2.3.1.2 for
related BBCK command detail
The BD command sends a
request for bias data to the PA. If
the PA_BD debug is enabled,
then the response is displayed on
the transmitter Terminal window.
Displays the binary protocol
version installed on the
transmitter
Used when the Clock Free (CF)
option is specified and internal
transmitter clock is in use
Report or set the hard bit rate or
set clock free bit rate to automatic
Examples:
BR
Report the bit rate
BR 5
Set the bit rate to 5 Mbps
BR A
Set the bit rate
automatically
Refer to section 4.2.3.1.3 for
additional BR command detail
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Setting
Required
Saved?
Standard
N/A
Standard
N/A
Standard
N/A
CF
Y
Factory
Default
N/A
N/A
N/A
BR 5
