TIMTER™ Multi-mode Dual
Telemetry Transmitter
Figure 9: One 4 x 3 Airborne IntelliCool™ Heat Sink Connected to a 4 x 3 Dual Transmitter (24xx Package)
2.3 Pre-wired MDM-15 for RS-422 Units
Part Number: QSX-AC-MDM15-36-PIN
An MDM-15 connector with 36" color-coded pigtail cables for connecting to transmitters with the RS-422 clock and
data baseband interface is shown in Figure 10.
Figure 10: Pre-wired MDM-15 with 36" Pigtails for RS-422
