Mnemonic Name
Command
VP Variable Power
XDC External Device
Control
XDF External Device
Frequency
Switching
Threshold
XDP External Device
Polarity Invert
ZC Show All
Parameters
66 Quasonix, Inc.
Description
Report or set variable power level
Typically the transmitter defaults
to full power (VP Max);
Valid range is 0-31 in 1 dB steps
or 0-31.5 in 0.5 dB steps,
depending on the transmitter
Examples:
VP Report the variable
power level
VP 31 Set variable power to 31
VP 5 Set variable power to 5
VP Max Set variable power to the
highest allowable value for the
unit
VP Min Set variable power to the
minimum allowable value for the
unit
Report or set the state of the
extra RS-422 output to use it to
control an external device
Refer to section 4.2.3.1.20 for
additional XDC command detail.
Report or set the frequency
threshold at which the extra RS-
422 output changes states
Refer to section 4.2.3.1.21 for
additional XDF command detail.
Report or set the polarity of the
extra RS-422 output
Refer to section 4.2.3.1.22 for
additional XDP command detail.
Displays all parameters and
global variables (mainly for
Quasonix factory use)
Examples:
ZC Show all configuration
parameters
ZC 2/C Show current parameters
for preset 2
Valid presets are 0-15; default is
0
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
VP Y
XD Y
XD Y
XD Y
Standard N/A
Factory
Default
VP Max
XDC 0
XDF
4400.0
XDP 0
