Mnemonic Name
Command
MRF Memory Read
Flash
MS Modulation
Scaling
53 Quasonix, Inc.
Description
Displays flash memory as bytes
and ASCII in the format
MRF address len
Address = Optional valid FLASH
starting address to display
Len = Number of bytes to read
Valid FLASH range is 000000 to
7FFFFF
Examples:
MRF Displays flash memory
from wherever it left off the last
time it was called
MRF 000070 3 Displays 3 bytes
starting at address 000070
Scales the deviation (modulation
index) of the transmitted signal
relative to the standard default
deviation and writes it to the
FPGA; the value is saved with the
configuration
Example:
For PCM/FM – if the standard
modulation index is 0.7, setting
MS to 2.0 scales a modulation
index of 1.4
Value range is 0.09 to 128.01
Refer to section 4.2.3.1.14 for
additional MS command detail
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard N/A
MS Y
Factory
Default
N/A
MS 1.0
