Quasonix TIMTER Installation And Operation Manual page 57

Mnemonic Name
Command
IR Read FPGA IO
Register
LC List
Configurations
49 Quasonix, Inc.
Description
Reads and displays any IO
register on the FPGA;
If a valid hex register address is
specified, the [len] dwords
starting at that address display.
If no length is specified, the last
length is used. Default on power
up is 10h.
If no address is specified, the last
address is reread and displayed.
Syntax:
IR addr [len]
Examples:
IR ? Show the IR syntax
IR 04C00074H 2 displays:
Data 0009313Ah read from IO
04C00074h
Data 2880004Ch read from IO
04C00078h
Lists the stored configurations on
the unit
If a configuration number is
supplied with the LC, then the
saved parameters for that
configuration are displayed.
These are the same
configurations used by presets.
Valid configurations 0-15
Examples:
LC List all internal saved
configurations
LC 7 Show configuration 7
details
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard N/A
Standard N/A
Factory
Default
N/A
N/A
