Quasonix TIMTER Installation And Operation Manual page 16

Part Number
Code
05
10
1.3.9 Packages
Package field codes are listed in Table 10. For questions about specific packages, please contact Quasonix.
Band
L or S band
L or S band
C band
C band
L/S band
L/S band
L/C, S/C, or L/S/C
band
Transmitter weight may vary depending on packages and applications. For information about the weight of a
particular transmitter, please contact Quasonix.
1.3.10 Automatic Carrier Wave Output Option — AC
This option allows the TIMTER to transmit a carrier wave when the clock input is absent, which would normally
cause the RF output to be turned off.
1.3.11 Auto Carrier Save Option – ACS
This option allows the TIMTER to transmit a carrier wave when the clock input is absent, which would normally
cause the RF output to be turned off, just like the AC option. ACS uses the saved setting of AC on power up instead
of forcing AC on like the legacy option.
1.3.12 Adapter Plate – AP
Use this option to include the 2.5" x 3.5" adapter plate (hardware accessory) with the order.
8 Quasonix, Inc.
Table 9: RF Output Power Codes
5 watts (+37 dBm), minimum per output
10 watts (+40 dBm), minimum per output
Table 10: Package Codes
Primary TIMTER™
Connector Package
Female 07AH
MDM-15
Male 07AN
MDM-15
Female 09AK
MDM-15
Male 09AM
MDM-15
Female 18AD
MDM-15
Male 18AE
MDM-15
Contact 24xx
Quasonix
TIMTER™ Multi-mode Dual
Telemetry Transmitter
RF Output Power
Volume Width
2.000"
7.200 in 3
2.000"
3
7.200 in
2.000"
3
9.450 in
2.000"
3
9.450 in
4.000"
3
18.420 in
4.000"
3
18.420 in
4.000"
3
22.200 in
Length Height
3.000" 1.200"
3.000" 1.200"
3.000" 1.575"
3.000" 1.575"
3.000" 1.535"
3.000" 1.535"
3.000" 2.000"
