Mnemonic Name
Command
ID Internal Data
Gen
IMN Internal Model
Number
47 Quasonix, Inc.
Description
Report or set the internal data
pattern
This setting is used if the Clock
and Data Source is set to internal
(CS 1).
When setting the data, the ID
name must be PN6, PN9, PN11,
PN15, PN17, PN20, PN23, PN31,
MARK, SPACE, ALT01, a valid 4
digit hexadecimal value, or
USER. If USER, two or more
arguments may be included in
format:
ID USER pattern bitlen
Pattern = A 32 bit hex pattern
Bitlen = Number of bits (1-32) in
the user pattern
Examples:
ID Report the internal data
pattern
ID PN15 Set internal data
pattern to PN15
ID USER AA55 Set internal data
pattern to 0xAA55
ID USER 5555 16
pattern to 16 bit pattern of 5555h
In SOQPSK mode, ID USER
5555 or ID USER AAAA will
result in an unmodulated carrier,
at the nominal carrier frequency.
Display the internal model
number for the transmitter
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Required
Standard
Set
Standard
Setting Factory
Saved? Default
Y ID PN15
N/A N/A
