Mnemonic Name
Command
HP High Power
HX eXtended Help
IC Internal Clock
Rate
46 Quasonix, Inc.
Description
Report or set high power level to
use with dual power option
Valid range is 0-31 in 1 dB steps
or 0-31.5 in 0.5 dB steps,
depending on the transmitter
Examples:
HP Report the present high
power level
HP 31 Set high power to 31
HP Max Set high power to the
highest allowable value for the
unit
HP Min Set high power to the
minimum allowable value for the
unit
Displays a list of additional help
commands
Report or set the internal clock
rate
This rate is used if the clock
source is set to internal (CS 1). It
should not be confused with "BR",
which sets the rate of the internal
bit sync, which phase locks to the
externally applied data, if Clock-
free is enabled.
If no argument is passed, the unit
reports the clock frequency. If a
valid frequency is given, the
internal clock frequency is set.
The frequency is in MHz.
Examples:
IC Display current internal
clock rate
IC 4.95 Set internal clock rate to
4.95 MHz
Valid range is 0.002 MHz –
46.000 MHz
Observes same bit rate limits as
HR/LR cmds (PCM/FM half)
Refer to section 4.2.3.1.10 for
additional IC command detail
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
DP Y
Standard N/A
Standard Y
Factory
Default
HP 31
N/A
IC 5
