Quasonix TIMTER Installation And Operation Manual page 68

Mnemonic Name
Command
RZ RF On/Off Pin
Polarity
SC Set
Configuration
Priority
SD Digital Pot
60 Quasonix, Inc.
Description
Set or show the polarity of the RF
On/Off pin, which is pulled high
internally to 3.3 VDC
RZ 0 means the RF is ON when
the RF On/Off pin is low
RZ 1 means the RF is ON when
the RF On/Off pin is high
(floating)
Examples:
RZ Show the current RF
On/Off polarity
RZ 0 Set RF On/Off polarity to
"pin low = on"
RZ 1 Set RF On/Off polarity to
"pin high = on"
The default polarity on most
Quasonix transmitters is high.
The RF On/Off pin is a hard OFF
control. No matter what state
everything else is in, setting this
switch input to the inactive state
will turn RF Off.
Set or show current configuration
priority setting.
Valid settings are:
1 – Ignore stored setting; read
frequency plug on power up
2 – Ignore frequency plug
(always)
Refer to section 4.2.3.1.17 for
additional SC command detail
This is a read only command;
Report the value of the digital pot
for HVA on the transmitter.
Operates on the currently
selected channel(s), or the
channel override
Range is 0 to 255
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard Y
DSWBX Y SC 1 or 2
additional
Standard N/A
Factory
Default
RZ 1
(refer to
detail)
255
