Mnemonic
Name
Command
CH
Current Channel
CHD
Channel
Difference
CLKS
Clock Source
CMNIO
Common IO
Display
CP
Clock Polarity
CR
Current Preset
40
Quasonix, Inc.
Description
Selects current channel for
commands
Valid options are:
2
Apply commands to
channel 1
2 Apply commands to channel 2
2
Apply commands to both
channels
Example:
CH
Report current channel
CH 1
Set current channel to 1
Report all differences between
the Channel 1 and Channel 2
configurations
Refer to section 4.2.3.1.7 for
additional CHD command detail
Refer to CS command
Displays common IO enable and
output registers
When ? entered as argument, bit
definitions for registers are listed
Example:
CMNIO ?
List bit definitions
Report clock polarity; the Dual
Transmitter only supports
Automatic clock polarity and
cannot be changed; Automatically
selects the most reliable clock
edge
Example:
CP
Display the current clock
polarity
Displays the currently loaded
preset
CR
Display current preset
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s)
Setting
Required
Saved?
Standard
Y
Standard
N
Standard
N
Standard
N/A
Standard
Y
Standard
N/A
Factory
Default
CH 1
N/A
CS 0
N/A
CP A
CR 0
