Quasonix TIMTER Installation And Operation Manual page 75

Mnemonic Name
Command
ZCP Show Critical
Parameters
ZF Show All
Options
ZR Show RAM
Variables
ZS Show Machine
State
ZX Show Preset
Inputs
ZY Show Connector
67 Quasonix, Inc.
Description
Displays the current value of all
critical parameters
Displays all options (like ZZ)
except ZF shows all options
whether enabled or not
Displays current value of all
global variables and all global
channel specific variables
Examples:
ZR Show all variables
ZR G Show globals only
ZR 1 Show Channel 1 specific
variables only
ZR 2 Show Channel 2 specific
variables only
Displays all of the machine
registers for a specified block; if
no block is specified, blocks 0
and 1 are displayed
Block range is 0-3
Examples:
ZS Show blocks 0 and 1
ZS 3 Show block 3
Displays the current preset inputs
on the parallel connector
Available presets depend on the
number specified for the unit
Values are PS2, PS4, PS8, or
PS16
If the PS option is not specified,
there is only one (1) hardware
preset on the transmitter.
Displays the transmitter's
baseband connector pinout with
proper gender, numbering, and
signal labeling
Valid only with standard 15-pin
transmitters
TIMTER™ Multi-mode Dual
Telemetry Transmitter
Option (s) Setting
Required Saved?
Standard N/A
Standard N/A
Standard N/A
Standard N/A
PSn N/A
Standard N/A
Factory
Default
N/A
N/A
N/A
N/A
N/A
N/A
