SuperServer SYS-122H-TN: Maintenance and Component Installation
PCIe Cables - Expansion Card/AIOM OCP 3.0 NIC Slots
Figure 3-51. PCIe Cables - Expansion Card/AIOM OCP 3.0 NIC Slots
Expansion Card/AIOM OCP 3.0 NIC Slots
Cable Part
Cable
Number
CBL-MCIO-
1
1221M5RE
CBL-MCIO-
2
1228M5RE
3 CBL-GNZ5-1307
Connection
Connection To
From
Motherboard, Riser Card,
JPCIE4A1 JPCIE2A1
Motherboard, Riser Card,
JPCIE4B1 JPCIE2B1
Motherboard, AIOM/OCP 3.0
JAIOM1 NIC
90
Reference
Expansion Card Slot 3
(x16)
AIOM OCP 3.0 NIC Slot
A1 (x16)
