Cable Cable Part Number
CBL-MCIO-
4
1448M5FA4
CBL-MCIO-
5*
1434M5FA5
CBL-MCIO-
6
1439M5FA6
*This cable connection provides a NVMe SMBus and/or NVMe VPP bus communication links between
the system and the storage backplane. NVMe devices attached to the storage backplane may have
detection or hot-swap issues if this cable not connected properly.

Storage Cables - SAS/SATA

Cable Part
Cable
Number
CBL-SAST-
1
1273LP-100
SuperServer SYS-122H-TN: Maintenance and Component Installation
Storage Cables - NVMe
Connection Form
Motherboard,
JPCIE6A2
Motherboard, P2_
NVME0
Motherboard, P2_
NVME3
Figure 3-50. Storage Cables -SAS/SATA
Storage Cables - SAS/SATA
Connection
From
Storage Card,
CN0
88
Connection To
Left Backplane, CN4
Right Backplane,
CN1
Right Backplane,
CN2
Connection To
Left Backplane, JSM1
& JSM2
Reference
Drives 6-7
Drives 8-9
Drives 10-
11
Reference
Drives 0-7
