  • Page 1 SuperServer ® SYS-110D-4C-FRAN8TP SYS-110D-4C-FRDN8TP SYS-110D-8C-FRAN8TP SYS-110D-8C-FRDN8TP SYS-110D-14C-FRAN8TP SYS-110D-14C-FRDN8TP SYS-110D-16C-FRAN8TP SYS-110D-16C-FRDN8TP SYS-110D-20C-FRAN8TP SYS-110D-20C-FRDN8TP USER’S MANUAL Revision 1.0b...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    SuperServer SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................9 1.2 System Features ........................10 Front View .........................10 Control Panel .........................11 Power Supply Indicators ....................12 Rear View ..........................13 Top View ..........................14 1.3 System Architecture ......................15 Main Components ......................15 1.4 Motherboard Layout ......................16 Quick Reference Table ......................17 Motherboard Block Diagram .....................19 Motherboards ........................20...
  • Page 5 Preface 2.7 Connecting Power and Ground in a NEBS environment ...........28 DC Power Source, Power Connection, and Grounding............28 Chassis Ground Stud connections for AC and DC systems ..........29 Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................30 3.2 Accessing the System ......................31 3.3 Memory ..........................32 Memory Support ........................32 General Guidelines for Optimizing Memory Performance ..........32...
  • Page 6 SuperServer SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP/110P-FRDN2T User's Manual 4.4 Jumpers ..........................61 4.5 LED Indicators ........................65 Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................67 5.2 Driver Installation ........................69 5.3 SuperDoctor 5 ........................70 ® 5.4 BMC ............................71 BMC ADMIN User Password ....................71 Chapter 6 Optional Components 6.1 Optional Parts List ......................72 6.2 Power Cable ........................72 6.3 Air Shrouds .........................72...
  • Page 7 Preface 7.9 Reporting an Issue ......................86 Technical Support Procedures ..................86 Returning Merchandise for Service ...................87 Vendor Support Filing System ..................87 7.10 Feedback ...........................87 Appendix A Standardized Warning Statements for AC Systems Appendix B Standardized Warning Statements for DC Systems Appendix C System Specifications 電源...
  • Page 8 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 9: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the SuperServer SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP. It is based on the X12SDV-4C/8C/14C/16C/20C-SPT8F motherboard and the CSE-515M-R000NP2 chassis. The following provides an overview of the specifications and capabilities. System Overview Motherboard X12SDV-4C/8C/14C/16C/20C-SPT8F...

  • Page 10: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix C for additional specifications. Front View BMC LAN Port Two 10G VGA Port BASE-T Control Panel USB Ports LAN Ports Service Tag Rack Ear Bracket Rack Ear Bracket T w o...

  • Page 11: Control Panel

    Chapter 1: Introduction Control Panel HDD LED NIC LEDs Information LED Power LED UID Button Power Button Figure 1-2. Control Panel Control Panel Features Feature Description Solid red indicates an overheated condition. Information LED 1Hz blinking red indicates a fan failure. NIC2 LED Flashing indicates network activity on LAN port 2.

  • Page 12: Power Supply Indicators

    Chapter 1: Introduction Power Supply Indicators Power Supply Indicators Power Supply Condition Green LED Amber LED No AC power to power supply Power supply critical events causing a shutdown/failure/OCP/OVP/fan failure/ OTP/UVP Power supply warning events when the power supply continues to operate, high Blinking at 1 Hz temperature, over voltage, under voltage, etc.

  • Page 13: Rear View

    Chapter 1: Introduction Rear View Power Supply 2 Power Supply 1 Fans Figure 1-3. SYS-110D-4C/8C/14C/16C/20C-FRAN8TP: Rear View Power Supply 2 Power Supply 1 Fans Figure 1-4. SYS-110D-4C/8C/14C/16C/20C-FRDN8TP: Rear View System Features: Rear Feature Description Power Supplies Two redundant power supply modules, PWS1 on the right, PWS2 on the left Fans Five system fans...

  • Page 14: Top View

    Chapter 1: Introduction Top View Fixed HDD Bays Processor 4 DIMM Slots 1 M.2 Slot Power Supply Module(s) 5 System Fans Figure 1-5. System: Top View System Features: Top Feature Description Dual redundant 800 W module (SYS-110D-4C/8C/14C/16C/20C-FRAN8TP) or Power Supply Dual redundant 600 W modules (SYS-110D-4C/8C/14C/16C/20C-FRDN8TP) M.2 slot Single PCIe 3.0 x4/SATA3 M.2...

  • Page 15: System Architecture

    Chapter 1: Introduction 1.3 System Architecture This section covers the locations of the system electrical components of the motherboard and the overall system. Main Components RSC-S-6G4 X12SDV-4C/8C/14C/16C/20C-SPT8F Figure 1-6. Main Component Locations...

  • Page 16: Motherboard Layout

    Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the X12SDV-4C-SPT8F motherboard with jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4 or the motherboard...

  • Page 17: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBM1 IPMI Share LAN Enable/Disable Pins 1-2 Open (Enabled) JBM2 IPMI Dedicated LAN Enable/Disable Pins 1-2 Open (Enabled) JBT1 CMOS Clear Open (Normal) JNS1 OCuLink to SATA3.0 or PCIe 3.0 Selection Pins 2-3 (PCIe x4) JPG1 VGA Enable/Disable...
  • Page 18 Chapter 1: Introduction Connector Description JPWR1 24-pin ATX Power Connector (Required) JPV1 8-pin CPU Power Connector (Required) JRK1 Intel RAID Key Header JSD1 SATA DOM Power Connectors JSFPLED1 LAN7/8 Activity LED Header JSLIM1, JSLIM2 PCIe 4.0 x8 SlimSAS Connector JSTBY1 Standby Power Header JTGLED2 LAN5/6 Activity LED Header...

  • Page 19: Motherboard Block Diagram

    Chapter 1: Introduction Motherboard Block Diagram DDR4 up to 3200 DDR4 up to 3200 PCIe 4.0 x8 PCIe 4.0 x16 Slim SAS x8 PCIe SLOT6 PE1[7:0] PE0[15:0] PCIe 4.0 x8 Slim SAS x8 PE1[15:8] 25G PHY SFP1 PCIe 3.0 x4 / 4x SATA3.0 Flexible I/O Oculink x4 Quad0...

  • Page 20: Motherboards

    Chapter 1: Introduction Motherboards The table below lists the systems and their corresponding motherboards and processors. Systems SYS-110D-4C-FRAN8TP SYS-110D-8C-FRAN8TP SYS-110D-14C-FRAN8TP SYS-110D-16C-FRAN8TP SYS-110D-20C-FRAN8TP Feature SYS-110D-4C-FRDN8TP SYS-110D-8C-FRDN8TP SYS-110D-14C-FRDN8TP SYS-110D-16C-FRDN8TP SYS-110D-20C-FRDN8TP Motherboard X12SDV-4C-SPT8F X12SDV-8C-SPT8F X12SDV-14C-SPT8F X12SDV-16C-SPT8F X12SDV-20C-SPT8F Processor D-2712T D-2733NT D-2766NT D-2775TE D-2796NT Number of Cores Cache 15 MB...

  • Page 21: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 3 for details on installing those specific components.

  • Page 22: Rack Precautions

    Chapter 2: Server Installation • This product is not suitable for use with visual display workplace devices according to §2 of the German Ordinance for Work with Visual Display Units. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.

  • Page 23: Airflow

    Chapter 2: Server Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 24: Identifying The Sections Of The Rack Rails

    Chapter 2: Server Installation 2.4 Identifying the Sections of the Rack Rails The chassis package includes two rack rail assemblies in the rack mounting kit. Each as- sembly consists of two sections: an inner fixed chassis rail that secures directly to the server chassis and an outer fixed rack rail that secures directly to the rack itself.

  • Page 25: Inner Rails

    Chapter 2: Server Installation Inner Rails The inner rails are pre-attached to the chassis, but should the need arise to remove them, reinstallation of the rails is simple and can be accomplished with a screwdriver. Installing the Inner Rails 1. Place the inner rail on the side of the chassis aligning the hooks of the chassis with the inner rail holes.

  • Page 26: Outer Rails

    Chapter 2: Server Installation Outer Rails Outer rails attach to the rack and hold the server in place. The outer rails for the chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack 1. Attach the short bracket to the outside of the long bracket. Align the pins of the rail with the slides.

  • Page 27: Installing The Chassis Into The Rack

    Chapter 2: Server Installation 2.5 Installing the Chassis into the Rack 1. Confirm that the chassis includes the inner rails and rail extensions. Also, confirm that the outer rails are installed on the rack. 2. Align the chassis rails with the front of the rack rails. 3.

  • Page 28: Connecting Power And Ground In A Nebs Environment

    Safety Ground, indicated by “Earth GND Symbol”. (Optional because Chassis GND stud is connected) • +Return, positive terminal (Battery Return, BR). Supermicro provides a cable for connection to the DC power supply. You should use the provided cable or an equivalent cable with the following specifications: • Positronic CBD connector.

  • Page 29: Chassis Ground Stud Connections For Ac And Dc Systems

    Chapter 2: Server Installation Note: The SYS-110D-4C/8C/14C/16C/20C-FRDN8TP is DC-I and can be grounded in both CBN and IBN networks. It is suitable for installation in Network Telecommunication Facilities and in locations where the NEC applies. Connection of the +Return (BR) supports both North America, Isolated GP (single point connection to CBN) and Europe, Integrated GP (Multiple point connection to CBN) configurations.

  • Page 30: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 31: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The CSE-515M-R000NP2 chassis features a removable top cover, which allows easy access to the inside of the chassis. Removing the Chassis Cover 1. Power down the system as described in Section 3.1. 2.

  • Page 32: Memory

    LRDIMM-3DS (4R/8R) x4 4H-128 GB 2933 4H-256 GB Check the Supermicro website for possible updates to memory support. General Guidelines for Optimizing Memory Performance • For optimal performance, use DDR4 memory of the same type, size, and speed. • Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

  • Page 33: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation J10G_PWR JVRM1 JPTG1 COM1 JIPMB1 1. Insert the desired number of DIMMs IPMI_LAN LAN 3/4 LAN 1/2 USB 4/5(3.0) JBM1 JBM2 JPH1 into the memory slots based on the JPI2C1 LEDBMC JMD1_SRW1 JOPPS recommended DIMM population table.

  • Page 34: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.4 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system. 1.

  • Page 35: Storage Drives

    SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP system page. Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website product pages. Hard Drives Your server may or may not have come with fixed internal hard drives installed. Up to two 2.5"...

  • Page 36: Installing Drives

    Chapter 3: Maintenance and Component Installation Installing Drives The system supports two SATA3 drives by default. Installing 2.5" Drives to the Chassis Floor 1. Obtain the mounting bracket and secure the drive(s) to the bracket. 2. Secure the drives to the chassis floor using four screws. 3.

  • Page 37: Pcie Expansion Cards

    Chapter 3: Maintenance and Component Installation 3.6 PCIe Expansion Cards The system includes a pre-installed riser card that positions one PCIe x16 card at a 90 degree angle in the top slot. Note that the system does not support an expansion card in the bottom slot.
  • Page 38 Chapter 3: Maintenance and Component Installation 4. Insert the expansion card into the riser card slot while aligning the card rear bracket with the chassis slot. 5. Secure the card bracket with screws. One Expansion Card Screws Figure 3-6. Inserting the Expansion Card into the Riser Card Bracket 6.

  • Page 39: Installing M.2 Solid State Drives

    Chapter 3: Maintenance and Component Installation Installing M.2 Solid State Drives The X12SDV-4C/8C/14C/16C/20C-SPT8F supports PCIe 3.0 x4 NVMe/SATA M.2 SSDs. The M.2 slot supports the 2280 and 2242 form factors. Installing M.2 Drives 1. Remove power from the system and then remove the top cover as described in Sections 3.1 and 3.2.

  • Page 40: System Cooling

    Chapter 3: Maintenance and Component Installation 3.7 System Cooling The SuperServer SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP comes with five counter- rotating, hot-swappable fans and two air shrouds. Make sure the chassis top cover makes a good seal so the cooling air circulates properly through the chassis. Fans Five 4-cm fans provide the cooling for the system.

  • Page 41: Air Shrouds

    Chapter 3: Maintenance and Component Installation Lever Figure 3-9. Replacing the System Fans Air Shrouds The SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP supports two air shrouds, one to direct airflow to the CPU and another to direct airflow to the PCIe cards. There are two types of PCIe card air shrouds, one for full-height cards and one for half-height cards.
  • Page 42 Chapter 3: Maintenance and Component Installation Optional Figure 3-10. Installing Air Shrouds for CPU and Half-Height Half-Length GPU Cards...
  • Page 43 Chapter 3: Maintenance and Component Installation Optional Figure 3-11. Installing Air Shrouds for CPU and Optional Full-Height Full-Length Cards Incorrect Incorrect Correct...

  • Page 44: Checking The Server Air Flow

    Chapter 3: Maintenance and Component Installation Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • Use only recommended server parts. • Make sure no wires or foreign objects obstruct air flow through the chassis. Pull all excess cabling out of the airflow path or use shorter cables.

  • Page 45: Power Supply

    The SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP includes a redundant power supply, which allows the server to continue running when one power supply has been removed. Replacement units can be ordered directly from Supermicro. Replacing the Power Supply (SYS-110D-4C/8C/14C/16C/20C-FRAN8TP) 1. Use the system's remote management to find the failed power supply.
  • Page 46 Chapter 3: Maintenance and Component Installation 3. Disconnect the power cord from the power strip or outlet. 4. Disconnect the power cord from the power supply inlet. 5. Push the release button towards the handle. 6. Using the handle, pull the power supply out of the chassis. 7.
  • Page 47 Chapter 3: Maintenance and Component Installation Replacing the Power Supply (SYS-110D-4C/8C/14C/16C/20C-FRDN8TP) 1. Use the system's remote management to find the failed power supply. 2. Check the power supply's LED. Power Supply LED States LED Color Definition No power input Amber Power supply is off or failed Power supply is on and Green...
  • Page 48 Chapter 3: Maintenance and Component Installation Release Button Figure 3-15. Removing the Power Supply Note: The figure above is intended to show the power supply locations only. The chassis and serverboard may differ from those found in the SYS-110D-4C/8C/14C/16C/20C-FR(A/D)N8TP.

  • Page 49: Cable Routing Diagram

    Chapter 3: Maintenance and Component Installation 3.9 Cable Routing Diagram Refer to the diagram below for a representation of how the main cables are routed throughout the system. When disconnecting cables to add or replace components, refer to this diagram when adding or replacing components so you can reroute them in the same manner.

  • Page 50: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 51: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Headers Chassis Intrusion A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to the table below for pin definitions.
  • Page 52 Chapter 4: Motherboard Connections Disk On Module Power Connector The Disk On Module (DOM) power connector at JSD1 provides 5 V power to a solid-state DOM storage device connected to one of the SATA ports. Refer to the table below for pin definitions.
  • Page 53 The M.2 slot on the motherboard supports PCIe 3.0 x4/SATA SSD cards in the 2242 and 2280 form factors. NVMe I C Header Connector JNVI C1 is a management header for the Supermicro AOC NVMe PCIe peripheral cards. Connect the I C cable to this connector.
  • Page 54 SATA 3.0 Ports This motherboard has two SATA 3.0 ports (I-SATA0, I-SATA1). I-SATA0 can be used with Supermicro SuperDOM's SATA DOM connectors with power pins built in, and do not require external power cables. Supermicro SuperDOMs are backward compatible with regular SATA HDDs or SATA DOMs that need external power cables.
  • Page 55 A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support and Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Visit the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...

  • Page 56: Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 57 Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS). To turn off the power when the system is in suspend mode, press the button for 4 seconds or longer.
  • Page 58 Chapter 4: Motherboard Connections NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 59: Input/Output Ports

    Chapter 4: Motherboard Connections 4.3 Input/Output Ports Rear I/O Ports See the figure below for the locations and descriptions of the I/O ports on the rear of the motherboard. Rear I/O Ports Description Description Description Description BMC LAN LAN1 (1GbE) LAN5 (10G BASE-T) UID Switch USB5...
  • Page 60 Note: UID can also be triggered via BMC on the motherboard. For more information on BMC, please refer to the BMC User's Guide posted on our website at https://www. supermicro.com/manuals/other/BMC_Users_Guide_X12_H12.pdf. UID Switch UID LED Pin Definitions...

  • Page 61: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 62 Chapter 4: Motherboard Connections BMC Dedicated LAN Enable/Disable Use JBM2 to enable or disable the dedicated BMC LAN port. Refer to the table below for jumper settings. BMC Dedicated LAN Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 (Open) Enabled (Default) Pins 1-2 (Short) Disabled BMC Share LAN Enable/Disable...
  • Page 63 Chapter 4: Motherboard Connections ME Manufacturing Mode Close pins 2-3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturing mode, which will allow the user to flash the system firmware from a host server for system setting modifications.
  • Page 64 Chapter 4: Motherboard Connections Watchdog Watchdog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1-2 to reset the system if an application hangs. Close pins 2-3 to generate a non-maskable interrupt (NMI) signal for the application that hangs. Refer to the table below for jumper settings.

  • Page 65: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators BMC Heartbeat LED LEDBMC is the BMC Heartbeat LED. When the LED is blinking green, BMC is working. Refer to the table below for the LED status. BMC Heartbeat LED LED Color Definition Green: Blinking BMC Normal RJ45 LAN LEDs...
  • Page 66 Chapter 4: Motherboard Connections Overheat/Fan Fail/Power Fail LED LED3 is the Overheat/Fan Fail/Power Fail LED. Refer to the table below for more information. Overheat/Fan Fail/Power Fail LED LED Color Definition Solid Red System Overheat Blinking Red Fan Fail or PWR Fail Onboard Power LED LEDPWR is the onboard Power LED.

  • Page 67: Chapter 5 Software

    1. Create a method to access the Microsoft Windows installation ISO file. That can be a USB flash or media drive. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 68 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 69: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash or media drive.

  • Page 70: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 71: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: https://www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 72: Chapter 6 Optional Components

    The JTPM1 header is used to connect a Trusted Platform Module (TPM). A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Details and installation procedures are at: http://www.supermicro.com/manuals/other/TPM.pdf.

  • Page 73: Chapter 7 Troubleshooting And Support

    Chapter 7: Troubleshooting and Support Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by the Products option. •...

  • Page 74: Direct Links For General Support And Information

    SuperDoctor5 Large Deployment Guide For validated memory, use our Product Resources page Product Matrices page for links to tables summarizing specs for systems, motherboards, power supplies, riser cards, add-on cards, etc. Security Center for recent security notices Supermicro Phone and Addresses...

  • Page 75: Baseboard Management Controller (Bmc)

    The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC. For general documentation and information on BMC, please visit our website at: https://www. supermicro.com/manuals/other/BMC_Users_Guide_X12_H12.pdf. Figure 7-2. BMC Sample...

  • Page 76: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. General Technique J10G_PWR JVRM1...

  • Page 77: No Video

    • Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. • Storage drives: Make sure that all drives work properly. Replace if necessary.
  • Page 78 Also check the Control panel Overheat LED. • Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Refer to the Supermicro website for the minimum power requirements. •...

  • Page 79: Crash Dump Using Bmc

    In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using BMC. The BMC manual is available at https://www.supermicro.com/en/solutions/ management-software/bmc-resources. Check BMC Error Log 1.

  • Page 80: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 81 USB flash or media drive. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 82 Chapter 7: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 83 Chapter 7: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 84 Chapter 7: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 85: Cmos Clear

    Chapter 7: Troubleshooting and Support 7.6 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 86: Where To Get Replacement Components

    7.7 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 87: Returning Merchandise For Service

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.10 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.

  • Page 88: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 89 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 90 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 91 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 92 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 93 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 94 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 95 Appendix A: Warning Statements ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 96 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 97 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 98 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 99 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 100 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 101 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 102 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 103 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 104 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 105 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 106 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 107 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 108: Appendix B Standardized Warning Statements For Dc Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 109 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 110 Appendix B: Standardized Warning Statements ‫תקנון הצהרות אזהרה‬ ‫הצהרות הבאות הן אזהרות על פי תקני התעשייה, על מנת להזהיר את המשתמש מפני חבלה‬ ‫פיזית אפשרית. במידה ויש שאלות או היתקלות בבעיה כלשהי, יש ליצור קשר עם מחלקת תמיכה‬ .‫טכנית של סופרמיקרו. טכנאים מוסמכים בלבד רשאים להתקין או להגדיר את הרכיבים‬ .‫יש...
  • Page 111 Appendix B: Standardized Warning Statements Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
  • Page 112 Appendix B: Standardized Warning Statements Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 60VDC, 20A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が60VDC、 20Aを超えないこ とを確認下さい。 警告...
  • Page 113 Appendix B: Standardized Warning Statements ‫מוצר זה מסתמך על הגנה המותקנת במבנים למניעת קצר חשמלי. יש לוודא כי‬ 60VDC, 20A-‫המכשיר המגן מפני הקצר החשמלי הוא לא יותר מ‬ ‫هذا املنتج يعتمد عىل معداث الحاميت مه الدوائ ر القصرية التي تم تثبيتها يف‬ ‫املبنى‬...
  • Page 114 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 115 Appendix B: Standardized Warning Statements Attention Le système doit être débranché de toutes les sources de puissance ainsi que de son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour installer ou enlever des composants de systéme. ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬...
  • Page 116 Appendix B: Standardized Warning Statements Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可されていま す。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.
  • Page 117 Appendix B: Standardized Warning Statements Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. (This warning does not apply to workstations). アクセス制限区域...
  • Page 118 Appendix B: Standardized Warning Statements ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ (.‫'כלי אבטחה בלבד (מפתח, מנעול וכד‬ . ‫تخصيص هذه انىحذة نترك ب ُ ها ف مناطق محظورة تم‬ ‫،...
  • Page 119 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 120 Appendix B: Standardized Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 121 Appendix B: Standardized Warning Statements Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden. ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones.
  • Page 122 Appendix B: Standardized Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 123 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 124 Appendix B: Standardized Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 125 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 126 Appendix B: Standardized Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 127 Appendix B: Standardized Warning Statements DC Power Supply Warning! When stranded wiring is required, use approved wiring terminations, such as closedloop or spade-type with upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the insulation and conductor. 警告...
  • Page 128 Appendix B: Standardized Warning Statements ‫وأ ةقلغم ةقلح لثم ،اهيلع ةقفاوملا ءاهنإ كالسألا مادختساو ،لبسلا مهب تعطقت نيذلا كالسألا ابولطم نوكي امدنع‬ ‫بجيو كالسألل بسانملا مجحلا نوكي تاءاهنإلا هذهل يغبنيو .ةبولقم تاورعلا عم عونلا ةيقيقحلا اهئامسأب ءايشألا‬ ‫.لصومو لزعلا نم لك حبك‬ 주의! 꼬인...
  • Page 129 Appendix B: Standardized Warning Statements 警告 進行以下任一操作程序前，請確保直流電路已斷電。 警告 请在进行以下任一操作程序前，确保直流电路的电源已经断开。 Warnung Vor Ausführung der folgenden Vorgänge ist sicherzustellen, daß die Gleichstromschaltung keinen Strom erhält. ¡Advertencia! Antes de proceder con los siguientes pasos, comprobar que la alimentación del circuito de corriente continua (CC) esté cortada (OFF). Attention Avant de pratiquer l'une quelconque des procédures ci-dessous, vérifier que le circuit en courant continu n'est plus sous tension.
  • Page 130 Appendix B: Standardized Warning Statements Hazardous Voltage or Energy Present on DC Power Terminals Warning! Hazardous voltage or energy may be present on DC power terminals. Always replace cover when terminals are not in service. Be sure uninsulated conductors are not accessible when cover is in place.
  • Page 131 Appendix B: Standardized Warning Statements ‫امدنع امئاد ءاطغ لادبتسا .ةمصاعلا ةقاطلا تاطحم ىلع ةدوجوم نوكت ةقاطلا وأ ةرطخلا دهجلا دق‬ ‫ءاطغلا امدنع اهيلإ لوصولا نكمي ال لوزعم ريغ تالصوملا هيف كش ال امم .ةمدخلا يف تسيل تاطحملا‬ ‫.هناكم يف‬ 주의! DC전원...

  • Page 132: Appendix C System Specifications

    Appendix C: System Specifications Appendix C System Specifications Processors Intel® Xeon D Ice Lake 4/8/14/16/20 Cores Processor from 65 W to 120 W Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset System on Chip BIOS 256Mb AMI BIOS®...
  • Page 133 Appendix C: System Specifications Power Supply SYS-110D-4C/8C/14C/16C/20C-FRAN8TP: PWS-804P-1R, 800W AC Redundant Power Supplies with PMBus; 80 Plus Platinum Level Certified Output Voltages: 750 W: 100 to 127 Vac 800 W: 200 to 240 Vac 800 W: 230 to 240 Vdc Input Currents: 750 W: 100 to 127 Vac, 10 A 800 W: 200 to 240 Vac, 5.5 A...
  • Page 134 Appendix C: System Specifications Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN/BS 55032 EN/BS 55035 CISPR 32 CISPR 35 EN/BS 61000-3-2 EN/BS 61000-3-3 EN/BS 61000-4-2 EN/BS 61000-4-3 EN/BS 61000-4-4 EN/BS 61000-4-5...

  • Page 135: Bsmi/Rhos

    Appendix C: System Specifications BSMI/RHoS (AC 電源) 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 伺服器 / Server 設備名稱： Equipment name 515M-R8X12 型號（型式）： Type designation (Type) (系列型號: 515M -8, SYS-110D-20C-FRAN8TP, SYS-110D-16C-FRAN8TP, SYS-110D-8C-FRAN8TP, SYS-110D-4C-FRAN8TP, SYS-110D-14C-FRAN8TP ) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元...
  • Page 136 Appendix C: System Specifications 警告: 為避免電磁干擾, 本產品不應安裝或使用於住宅環境。 輸入額定 100-240V ~, 60-50Hz, 10-5.5A (x2) *使用者不能任意拆除或替換內部配備 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...

  • Page 137: Bsmi/Rhos

    Appendix C: System Specifications BSMI/RHoS (DC 電源) 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 伺服器 / Server 設備名稱： Equipment name 515M-R6DX12 型號（型式）： Type designation (Type) (系列型號: 515M -6D, SYS-110D-20C-FRDN8TP、SYS-110D-16C-FRDN8TP、SYS-110D-8C-FRDN8TP、 SYS-110D-4C-FRDN8TP, SYS-110D-14C-FRDN8TP ) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元...
  • Page 138 Appendix C: System Specifications 警告: 為避免電磁干擾, 本產品不應安裝或使用於住宅環境。 輸入額定 -44 - -65Vdc , 18-10A (x2) *使用者不能任意拆除或替換內部配備 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...

This manual is also suitable for:

Superserver sys-110d-4c-frdn8tpSuperserver sys-110d-8c-fran8tpSuperserver sys-110d-8c-frdn8tpSuperserver sys-110d-14c-fran8tpSuperserver sys-110d-14c-frdn8tpSuperserver sys-110d-16c-fran8tp ... Show all

Table of Contents
