LTR IIO Input
Use this feature to set the MSR 1FCh Bit[35]. The options are Take IIO LTR input and Ignore
IIO LTR input.
CPU1 Core Disable Bitmap Menu
►CPU1 Core Disable Bitmap
Available Bitmap[0]:
This feature displays the available Bitmap[0].
Available Bitmap[1]:
This feature displays the available Bitmap[1]. It is available when the number of CPU cores is
greater than 128.
Disable Bitmap[0]:
Enter 0 to enable this feature for CPU Core Bitmap[0]. Enter FFFFFFFFFFF to disable CPU
Core Bitmap[0]. Please note that the maximum CPU cores are available in each CPU package
and at least one core per CPU must be enabled. Disabling all cores is not allowed. The default
setting is 0.
Disable Bitmap[1]:
Enter 0 to enable this feature for CPU Core Bitmap[1]. Enter FFFFFFFFFFF to disable CPU
Core Bitmap[1]. Please note that the maximum CPU cores are available in each CPU package
and at least one core per CPU must be enabled. Disabling all cores is not allowed. The default
setting is 0. This feature is available when the number of CPU cores is greater than 128.
Chipset Configuration Menu
►Chipset Configuration
Warning! Setting the wrong values in this section may cause system to malfunction.
Uncore Configuration Menu
►Uncore Configuration
The following information is displayed.
Number of CPU
l
Current UPI Link Speed
l
