- Page 1 SuperServer 1029GQ-TRT 1029GQ-TNRT 1029GQ-TXRT 1029GQ-TVRT USER’S MANUAL Revision 2.0c...
- Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.
-
Page 4: Table Of Contents
SuperServer 1029GQ-T(N/X/V)RT User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................9 1.3 System Features ........................10 1.4 Server Chassis Features ....................11 Control Panel ........................11 Front Features ........................12 Rear Features ........................13 1.5 GPU Configurations ......................14 101029GQ-TNRT9GQ-TRT/14: PCI Version ..............14 1029GQ-TXRT: Add-on Module Version ................15 1029GQ-TVRT: Add-on Module Version ................16 1.6 Motherboard Layout ......................17... - Page 5 Preparing the CPU Socket for Installation..............36 Installing the Processor Heatsink Module ..............37 Memory ..........................38 Memory Support ......................38 Check the Supermicro website for possible updates to memory support....38 Memory Population Guidelines ..................39 Memory Population Sequence ..................39 DCPMM for DP Motherboards with 12 Slots, 82xx/62xx/52xx/42xx ......41 Installing Memory ......................42...
- Page 6 SuperServer 1029GQ-T(N/X/V)RT User's Manual Chapter 4 Motherboard Connections 4.1 Power Connections ......................55 4.2 Headers and Connectors ....................56 Control Panel .........................58 4.3 Ports ...........................61 4.4 Jumpers ..........................62 Explanation of Jumpers ....................62 4.5 LED Indicators ........................64 Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................65 5.2 Driver Installation ........................67 5.3 SuperDoctor 5 ........................68...
- Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
-
Page 8: Overview
SuperServer 1029GQ-T(N/X/V)RT User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the SuperServer 1029GQ-T(N/X/V)RT using the X11DGQ motherboard. It supports high-end graphics processing units (GPUs). Differences between the server models include: Chassis and Storage Drive Support System Model Chassis... -
Page 9: Unpacking The System
Chapter 1: Introduction In addition to the motherboard and chassis, several important parts that are included with the system are listed below. Main Parts List Description Part Number Quantity LAN Add-on Card AOM-PIO-I2XT-P Air Shroud MCP-310-11807-0B CPU Heatsinks SNK-P0067PS 9 (1029GQ-TRT, 1029GQ-TNRT) Fans (4-cm) FAN-0163L4 7 (1029GQ-TXRT, 1029GQ-TVRT) -
Page 10: System Features
SuperServer 1029GQ-T(N/X/V)RT User's Manual 1.3 System Features This section provides an overview of the main features of the 1029GQ-T(N/X/V)RT. System Features Motherboard X11DGQ Chassis 1029GQ-TRT, 1029GQ-TNRT: SC118GQETS-R2K05P2 1029GQ-TXRT, 1029GQ-TVRT: SC118GQPTS-R2K05P2 Dual Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP processors in a P (LGA3647) which offer two Intel UltraPath Interconnect (UPI) links of up to 10.4 GT/s Memory Twelve memory slots support up to 3TB of 3DS Load Reduced DIMM (3DS LRDIMM), Load Reduced DIMM... -
Page 11: Server Chassis Features
Chapter 1: Introduction 1.4 Server Chassis Features Control Panel The switches and LEDs located on the control panel are described below. See Chapter 4 for details on the control panel connections. Figure 1-1. Control Panel View Control Panel Features Item Feature Description Information LED... -
Page 12: Front Features
SuperServer 1029GQ-T(N/X/V)RT User's Manual Front Features The SC118GQ is a 1U rackmount chassis See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Drive Bays Two 2.5"... -
Page 13: Rear Features
Chapter 1: Introduction Rear Features The illustration below shows the features included on the rear of the chassis. The PCI expansion slots are used for different purposes on each server model as noted below. Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description... -
Page 14: Gpu Configurations
SuperServer 1029GQ-T(N/X/V)RT User's Manual 1.5 GPU Configurations 1029GQ-TRT/1029GQ-TNRT: PCI Version The 1029GQ-TRT offers four PCI-E 3.0 x16 slots that support four double-width GPUs plus two low-profile PCI-E 3.0 x16 slots. P40/P100/V100/coprocessor GPUs are supported. The 1029GQ-TNRT offers four PCI-E 3.0 x16 slots that support four double-width GPUs plus two low profile PCI-E 3.0 x16 and one PCI-E 3.0 x8 slots. -
Page 15: 1029Gq-Txrt: Add-On Module Version
Chapter 1: Introduction 1029GQ-TXRT: Add-on Module Version The 1029GQ-TXRT system supports four PASCAL SXM P100 GPUs installed on the AOM- SXM2 add-on module which is connected to the motherboard by two bridges. A direct connection between GPUs 1 and 4, and between GPUs 2 and 3 is provided by a double NVlink connection (40GB/s). -
Page 16: 1029Gq-Tvrt: Add-On Module Version
SuperServer 1029GQ-T(N/X/V)RT User's Manual 1029GQ-TVRT: Add-on Module Version This system supports four Volta SXM V100 GPUs installed on the AOM-SXMV add-on module which is connected to the motherboard by two bridges. A direct connection between all GPUs is a double NVlink connection (2x25 GB/s). Fastest connections are afforded when GPUs are added in pairs. -
Page 17: Motherboard Layout
Chapter 1: Introduction 1.6 Motherboard Layout Below is a layout of the X11DGQ with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. JSTBY1 JBT1 JSLOT6... -
Page 18: Quick Reference
SuperServer 1029GQ-T(N/X/V)RT User's Manual Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Chapter 4 JPME2 ME ManufactureMode Pins 1-2 (Normal) JWD1 Watch Dog Timer Enable Pins 1-2 (Reset) Connectors Description Battery (BT1) Onboard CMOS Battery FAN8/FAN9 CPU/System Cooling Fan Headers FAN_CTRL Fan 1-7 control header FAN_PWR1... -
Page 19: System Block Diagram
Chapter 1: Introduction System Block Diagram #F-1 #M-1 #E-1 #L-1 VCCP0 12v VCCP1 12v #D-1 #K-1 VR13 VR13 #C-1 #J-1 5+1 PHASE 5+1 PHASE UPI 10.4G /11.2G #B-1 #H-1 205W 205W #A-1 #G-1 CPU1 CPU2 PECI:30 PECI:31 SOCKET ID:0 SOCKET ID:1 DMI3 DMI3 PCI-E X16 G3 (RSC-GR-6-X) -
Page 20: Chapter 2 Server Installation
SuperServer 2029U-TN24R4T User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components. -
Page 21: Server Precautions
Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack. -
Page 22: Circuit Overloading
SuperServer 2029U-TN24R4T User's Manual Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern. -
Page 23: Installing The Rails
Chapter 2: Server Installation MCP-290-11809-0N 2.3 Installing the Rails This section provides information on installing the chassis into a rack unit with the rails 674 mm to 1048 mm provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided. -
Page 24: Releasing The Inner Rail
SuperServer 2029U-TN24R4T User's Manual MCP-290-11809-0N 674 mm to 1048 mm Releasing the Inner Rail To mount the rail onto the chassis, first release the inner rail from the outer and middle rails. Releasing the Inner Rail from the Middle and Outer Rails 1. -
Page 25: Installing The Inner Rails On The Chassis
Chapter 2: Server Installation Installing The Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. 2. Place the inner rail firmly against the side of the chassis, aligning the T-studs on the side of the chassis with the slotted holes in the inner rail. -
Page 26: Installing The Outer Rails On The Rack
SuperServer 2029U-TN24R4T User's Manual Installing the Outer Rails on the Rack The outer rail is actually two pieces that slide to lengthen. Installing the Outer Rails 1. Confirm that the left and right outer rails have been correctly identified. 2. Push the rail rear bracket to the rear until it clicks into place. Rear Figure 2-4. - Page 27 Chapter 2: Server Installation 4. Release the small locking lever on the inside of the middle rail and push the middle rail back into the outer rail. 5. On the front of the outer rail, swing open the locking latch. Locking Latch Figure 2-6.
-
Page 28: Installing Into The Rack
SuperServer 2029U-TN24R4T User's Manual 2.4 Installing into the Rack After the rails are installed on the chassis and on the rack, the server can be installed in the rack. Be sure to use sufficient personnel to lift it safely. Installing the Chassis into a Rack 1. -
Page 29: Removing The Chassis From The Rack
Chapter 2: Server Installation Removing the Chassis From the Rack 1. Lift the auto-lock latches and pull the chassis out the front of the rack until it stops. 2. To remove the chassis from the rack completely, press the release latches on each of the inner rails downward simultaneously and continue to pull the chassis out of the rack. -
Page 30: Chapter 3 Maintenance And Component Installation
SuperServer 1029GQ-T(N/X/V)RT User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system. -
Page 31: Accessing The System
Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The chassis features a removable two-piece top cover, which allows easy access to the inside. Removing the Top Cover 1. Begin by removing power from the system as described in Section 3.1. 2. -
Page 32: Motherboard Components
Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustration only. Your components may look different. -
Page 33: Overview Of The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module The Processor Heatsink Module (PHM) contains a heatsink, a processor carrier, and the processor. Heatsink with Thermal Grease Processor Carrier Processor Processor Heatsink Module Bottom View... -
Page 34: Creating The Processor Carrier Assembly
SuperServer 1029GQ-T(N/X/V)RT User's Manual Creating the Processor Carrier Assembly To install a processor into the processor carrier, follow the steps below: 1. Hold the processor with the LGA lands (gold contacts) facing up. Locate the small, gold triangle in the corner of the processor and the corresponding hollowed triangle on the processor carrier. -
Page 35: Assembling The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Assembling the Processor Heatsink Module After creating the processor carrier assembly, mount it onto the heatsink to create the processor heatsink module (PHM): 1. Note the label on top of the heatsink, which marks the heatsink mounting holes as 1, 2, 3, and 4. -
Page 36: Preparing The Cpu Socket For Installation
SuperServer 1029GQ-T(N/X/V)RT User's Manual Preparing the CPU Socket for Installation This motherboard comes with a plastic protective cover on the CPU socket. Remove it carefully to install the Processor Heatsink Module (PHM). CPU Socket with Plastic Protective Cover Remove the plastic protective cover from the CPU socket. -
Page 37: Installing The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Installing the Processor Heatsink Module After assembling the Processor Heatsink Module (PHM), install it onto the CPU socket: 1. Align hole 1 of the heatsink with the printed triangle on the CPU socket. See the left image below. -
Page 38: Memory
*4Gb DRAM density is only supported on speeds up to 2666 MT/s **Only the 82xx and 62xx series support 2933 MT/s; for other processors, memory speed as supported by the CPU. Check the Supermicro website for possible updates to memory support. -
Page 39: Memory Population Guidelines
Then, if using two DIMMs per channel, install the second DIMM in the black slot. The following memory population sequence table was created based on guidelines provided by Intel to support Supermicro motherboards. The diagram is for illustrative purposes; your motherboard may look different. - Page 40 SuperServer 1029GQ-T(N/X/V)RT User's Manual Memory Population for X11 DP Motherboard, 12 DIMM Slots When 1 CPU is Memory Population Sequence used: 1 CPU & 1 DIMM CPU1: P1-DIMMA1 1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1 1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1 1 CPU &...
-
Page 41: Dcpmm For Dp Motherboards With 12 Slots, 82Xx/62Xx/52Xx/42Xx
Chapter 3: Maintenance and Component Installation DCPMM Population for 2nd Gen Scalable Processors (82xx/62xx/52xx/42xx) Only 2nd Gen Scalable Processors support DCPMM modules. Symmetric Population within one CPU Modes P1/P2- P1/P2- P1/P2- P1/P2- P1/P2- P1/P2- Channel Config. DIMMF1 DIMME1 DIMMD1 DIMMA1 DIMMB1 DIMMC1 DCPMM DRAM1... -
Page 42: Installing Memory
SuperServer 1029GQ-T(N/X/V)RT User's Manual Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge. •... -
Page 43: Motherboard Battery
Chapter 3: Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in Section 3.1 and remove the cover as described in Section 3.2.. -
Page 44: Chassis Components
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www. -
Page 45: Internal Drives
Chapter 3: Maintenance and Component Installation Internal Drives The system supports one or two 2.5" fixed hard disk drives. The required parts, a mounting bracket, two SATA cables, and two SATA power cables are included with the standard "barebones" server. Installing Internal Drives 1. -
Page 46: Graphics Processing Units
SuperServer 1029GQ-T(N/X/V)RT User's Manual Graphics Processing Units The 1029GQ-TRT and 1029GQ-TNRT include riser cards to support double-width GPUs (four total). Models 1029GQ-TXRT and 1029GQ-TVRT support GPUs installed on the AOM-SXM2 or AOM-SXMV-P add-on modules. GPUs in 1029GQ-TXRT and 1029GQ-TVRT To take advantage of the high speeds, GPUs should be installed in pairs. If you are installing two Pascal GPUs only, use positions 2 and 3 for the fastest GPU connection. - Page 47 Chapter 3: Maintenance and Component Installation 4. Secure the GPU with eight screws. Screw in the four inside screws first in a diagonal pattern, then the four outside screws in a diagonal pattern. Be careful not to damage the surrounding elements. 5.
-
Page 48: Gpus In 1029Gq1029Gq-Tnrttrt And 48
SuperServer 1029GQ-T(N/X/V)RT User's Manual GPUs in 1029GQ-TRT and 1029GQ-TNRT These systems support up four GPUs such as NVIDIA V100 and P100, and two low-profile PCIe expansion cards. Installing the Front GPUs Install the front GPUs using the front riser card (RSC-GR-6-X). 1. - Page 49 Chapter 3: Maintenance and Component Installation Install the rear GPU using the rear riser card (RSC-G-A6) riser card. Installing the Rear GPU 1. Remove the chassis bracket. 2. Attach the riser card to the bracket. 3. Insert the GPU into the riser card slot. 4.
-
Page 50: System Cooling
SuperServer 1029GQ-T(N/X/V)RT User's Manual Cable Reference Table Cable P/N GPU Type, Connector Type, Length Quantity/Server CBL-PWEX-1026 GPUs such as NVIDIA V100 and P100 8-pin 35cm CBL-PWEX-1027 GPUs such as NVIDIA V100 and P100 8-pin 14cm Figure 3-13. GPU Cable Routing Note: Numbers in figure indicate logical GPU number from BMC (IPMI) System Cooling A row of 4-cm counter-rotating fans provide the cooling for the system (Nine fans on the... -
Page 51: Installing Fans
Chapter 3: Maintenance and Component Installation Installing Fans Fan speed is controlled by system temperature via IPMI. If a fan fails, the remaining fans will ramp up to full speed. Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan). -
Page 52: Air Shroud And Block
SuperServer 1029GQ-T(N/X/V)RT User's Manual Air Shroud and Block Cooling is also improved by means of an air block and an air shroud to channel the air flow. The mylar shroud covers the CPUs and memory. Installing the Air Shroud 1. Lay the chassis on a flat, stable surface and remove the chassis cover. 2. -
Page 53: Power Supply
Blinking Amber: When blinking, indicates that the power supply has a warning condition and continues to operate. • Solid Amber: When illuminated, indicates that the power supply is plugged in, and is in an abnormal state. The system might need service. Please contact Supermicro technical support. - Page 54 SuperServer 1029GQ-T(N/X/V)RT User's Manual Figure 3-17. Removing/Replacing a Power Supply Changing the Power Supply Module: 1. Unplug the AC cord from the module to be replaced. 2. On the back of the module, push the release tab sideways. 3. Pull the module out using the handle. 4.
-
Page 55: Chapter 4 Motherboard Connections
Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A serverboard layout indicating component locations may be found in Chapter 1. -
Page 56: Headers And Connectors
It allows the motherboard to deny access if the TPM associated with the storage drive is not installed in the system. TPM is available from Supermicro. Trusted Platform Module/Port 80 Header... - Page 57 Chapter 4: Motherboard Connections SGPIO Headers The I-SGPIO1 (Serial General Purpose Input/Output) header is used to communicate with the enclosure management chip on the backplane. SGPIO Header Pin Definitions Pin# Definition Pin# Definition Ground DATA Out Load Ground Clock No connection Standby Power The Standby Power header is located at JSTBY1 on the motherboard.
-
Page 58: Control Panel
SuperServer 1029GQ-T(N/X/V)RT User's Manual Control Panel JF1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard. - Page 59 Chapter 4: Motherboard Connections Reset Button The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to a hardware reset switch on the computer chassis. Reset Button Pin Definitions (JF1) Pin# Definition Reset Ground Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1.
- Page 60 SuperServer 1029GQ-T(N/X/V)RT User's Manual NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and the LED connection for LAN Port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.
-
Page 61: Ports
Chapter 4: Motherboard Connections 4.3 Ports Ethernet Ports Two LAN ports (LAN1/LAN2) and a dedicated IPMI LAN port are provided on the motherboard. LAN1/LAN2 are supported by the X540 on the AOM-PIO-i2XT card, which plugs into JSLOT6. The dedicated IPMI LAN is supported by the onboard AST 2500 BMC and accepts an RJ45 type cable. -
Page 62: Jumpers
SuperServer 1029GQ-T(N/X/V)RT User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations. - Page 63 Chapter 4: Motherboard Connections Manufacturing Mode Select Close JPME2 to bypass SPI flash security and force the system to use the Manufacturing Mode, which will allow you to flash the system firmware from a host server to modify system settings. Manufacturing Mode Select Jumper Settings Jumper Setting...
-
Page 64: Led Indicators
SuperServer 1029GQ-T(N/X/V)RT User's Manual 4.5 LED Indicators Ethernet Ports The Ethernet ports on the rear I/O panel each have two LEDs. The Activity LED indicates network activity when flashing. The Link LED may be green, amber or off to indicate the speed of the connection. -
Page 65: Chapter 5 Software
USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive. - Page 66 SuperServer 1029GQ-T(N/X/V)RT User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.
-
Page 67: Driver Installation
The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD. -
Page 68: Superdoctor ® 5
5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP). -
Page 69: Ipmi
The X11DGQ supports the Intelligent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm. -
Page 70: Chapter 6 Bios
SuperServer 1029GQ-T(N/X/V)RT User's Manual Chapter 6 BIOS 6.1 Introduction This chapter describes the AMI BIOS setup utility for the X11DGQ and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published. - Page 71 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro X11DGQ (Motherboard model) BIOS Version Build Date (of the BIOS) CPLD (Complex Programmable Logic Device) Version: This item displays the CPLD version used in the system.
-
Page 72: Advanced Setup Configurations
SuperServer 1029GQ-T(N/X/V)RT User's Manual 6.3 A dvanced Setup Configurations Use the arrow keys to select the Advanced tab and press <Enter> to access the submenu items. Caution: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. If this occurs, revert to the manufacture default settings. - Page 73 Chapter 6: BIOS Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
- Page 74 SuperServer 1029GQ-T(N/X/V)RT User's Manual • Processor ID • Processor Frequency • Processor Max Ratio • Processor Min Ratio • Microcode Revision • L1 Cache RAM • L2 Cache RAM • L3 Cache RAM • Processor 0 Version • Processor 1 Version Hyper-Threading (ALL) (Available when supported by the CPU) Select Enable to support Intel Hyper-threading Technology to enhance CPU performance.
- Page 75 Chapter 6: BIOS DCU Streamer Prefetcher (Available when supported by the CPU) Select Enabled to enable the DCU (Data Cache Unit) Streamer Prefetcher which will stream and prefetch data and send it to the Level 1 data cache to improve data processing and system performance.
- Page 76 SuperServer 1029GQ-T(N/X/V)RT User's Manual Turbo Mode This feature will enable dynamic control of the processor, allowing it to run above stock frequency. The options are Disable and Enable. Hardware PM State Control Hardware P-States If this feature is set to Disable, hardware will choose a P-state setting for the system based on an OS request.
- Page 77 Chapter 6: BIOS UPI Configuration UPI General Configuration The following UPI information will display: • Number of CPU • Number of IIO • Current UPI Link Speed • Current UPI Link Frequency • UPI Global MMIO Low Base / Limit • UPI Global MMIO High Base / Limit •...
- Page 78 SuperServer 1029GQ-T(N/X/V)RT User's Manual Memory Configuration Enforce POR Select Enable to enforce POR restrictions on DDR4 frequency and voltage programming. The options are Enabled and Disable. Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules. The options are Auto, 1333, 1400, 1600, 1800, 1867, 2000, 2133, 2200, and 2400.
- Page 79 Chapter 6: BIOS Correctable Error Threshold Use this item to specify the threshold value for correctable memory-error logging, which sets a limit on the maximum number of events that can be logged in the memory-error log at a given time. The default setting is 10. SDDC Select Enable for SDDC (Single Device Data Correction) support, which will increase the reliability and serviceability of your system memory.
- Page 80 SuperServer 1029GQ-T(N/X/V)RT User's Manual MCP0 (II0 PCIe Br4) This item configures the PCI-E port Bifuraction setting for a PCI-E port specified by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto. MCP1 (II0 PCIe Br5) This item configures the PCI-E port Bifuraction setting for a PCI-E port specified by the user.
- Page 81 Chapter 6: BIOS Socket 1 PcieBr1D00F0 - Port 1A/Socket 1 PcieBr2D00F0 - Port 2A/Socket 1 PcieBr3D00F0 - Port 3A/Socket 1 PcieBr4D00F0 - MCP 0/Socket 1 PcieBr5D00F0 - MCP 1 Link Speed Use this item to select the link speed for the PCI-E port specified by the user. The options are Auto, Gen 1 (2.5 GT/s), Gen 2 (5 GT/s), and Gen 3 (8 GT/s).
- Page 82 SuperServer 1029GQ-T(N/X/V)RT User's Manual Use this feature to enable Non-Isoch VT-d Engine Address Translation Services (ATS) support. ATS translates virtual addresses to physical addresses. The options are Enable and Disable. Posted Interrupt Use this feature to enable VT_D Posted Interrupt. The options are Enable and Disable. Coherency Support (Non-Isoch) Use this feature to maintain setting coherency between processors or other devices.
- Page 83 Chapter 6: BIOS South Bridge Legacy USB Support This feature enables support for USB 2.0 and older. The options are Enabled and Disabled. Default setting is Enabled. XHCI Hand-off When disabled, the motherboard will not support USB 3.0. Options are Enabled and Disabled.
- Page 84 SuperServer 1029GQ-T(N/X/V)RT User's Manual SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip. The options are Disable and Enable. Configure SATA as Select IDE to configure a SATA drive specified by the user as an IDE drive. Select AHCI to configure a SATA drive specified by the user as an AHCI drive.
- Page 85 Chapter 6: BIOS PCIe/PCI/PnP Configuration The following information will display: • PCI Bus Driver Version • PCI Devices Common Settings: Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Disabled and Enabled.
- Page 86 SuperServer 1029GQ-T(N/X/V)RT User's Manual CPU1/CPU2 SLOT5 - RSC-G-A66 Slot 1 PCI-E 3.0 x16 This item enables or disables this PCIe Slot OPROM option. The options are Disabled, Legacy, and EFI. Slot 2 PCI-E 3.0 x16 This item enables or disables this PCIe Slot OPROM option. The options are Disabled, Legacy, and EFI.
- Page 87 Chapter 6: BIOS Super IO Configuration The following Super IO information will display: • Super IO Chip AST2500 Serial Port 1 Configuration Serial Port Select Enabled to enable the onboard serial port specified by the user. The options are Enabled and Disabled. Device Settings This item displays the base I/O port address and the Interrupt Request address of a serial port specified by the user.
- Page 88 SuperServer 1029GQ-T(N/X/V)RT User's Manual Serial Port 2 Attribute Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redirectoin. The options are COM and SOL. Serial Port Console Redirection COM1 Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Enabled and Disabled.
- Page 89 Chapter 6: BIOS Stop Bits A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard serial data communication. Select 2 Stop Bits if slower devices are used. The options are 1 and 2. Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow.
- Page 90 SuperServer 1029GQ-T(N/X/V)RT User's Manual COM2/SOL Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection.
- Page 91 Chapter 6: BIOS Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
- Page 92 SuperServer 1029GQ-T(N/X/V)RT User's Manual Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
- Page 93 Chapter 6: BIOS WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) platform and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.
- Page 94 SuperServer 1029GQ-T(N/X/V)RT User's Manual Platform Hierarchy (for TPM Version 2.0 and above) Select Enabled for TPM Platform Hierarchy support which will allow the manufacturer to utilize the cryptographic algorithm to define a constant key or a fixed set of keys to be used for initial system boot.
- Page 95 Chapter 6: BIOS Current Status Information TXT Support Intel TXT (Trusted Execution Technology) helps protect against software-based atacks and ensures protection, confidentiality and integrity of data sotred or created on the system. Use this feature to enable to disable TXT Suppport. The options are Disabled and Enabled. Intel Virtual RAID on CPU ...
-
Page 96: Event Logs
SuperServer 1029GQ-T(N/X/V)RT User's Manual 6.4 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMbios Event Log Change this item to enable or disable all features of the SMBIOS Event Logging during system boot. - Page 97 Chapter 6: BIOS SMBIOS Event Long Standard Settings Log System Boot Event This option toggles the System Boot Event logging to enabled or disabled. The options are Disabled and Enabled. MECI The Multiple Event Count Increment (MECI) counter counts the number of occurences that a duplicate event must happen before the MECI counter is incremented.
-
Page 98: Ipmi
SuperServer 1029GQ-T(N/X/V)RT User's Manual 6.5 IPMI Use this tab page to configure IPMI settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. Status Of BMC (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system. System Event Log ... - Page 99 Chapter 6: BIOS When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
- Page 100 SuperServer 1029GQ-T(N/X/V)RT User's Manual Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1). VLAN Enabling this item displays the virtual LAN settings. The options are Enabled and Disabled. Update IPMI LAN Configuration Select Yes for the BIOS to implement all IP/MAC address changes at the next system boot.
-
Page 101: Security
Chapter 6: BIOS 6.6 Security Use this tab page to configure Security settings. Administrator Password Press Enter to create a new, or change an existing Administrator password. User Password Press Enter to create a new, or change an existing User password. Password Check Select Setup for the system to check for a password at Setup. - Page 102 SuperServer 1029GQ-T(N/X/V)RT User's Manual Attempt Secure Boot Use this item to enable secure boot. The options are Disabled and Enabled. Secure Boot Mode If Custom mode is enabled, Secure Boot variables can be configured without authentication. The options are Custom and Standard. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot.
- Page 103 Chapter 6: BIOS Authorized Signatures Set New Key Select Yes to load the database from the manufacturer's defaults. Select No to load the DB from a file. The options are Yes and No. Append Key Select Yes to add the database from the manufacturer's defaults to the existing DB. Select No to load the DB from a file.
-
Page 104: Boot
SuperServer 1029GQ-T(N/X/V)RT User's Manual Append OsRecovery Signature This item uploads and adds an OSRecovery Signature into the Key Management. You may insert a factory default key or load from a file. When prompted, select "Yes" to load Factory Defaults or "No' to load from a file. To set this feature, select Restore User Defaults from the Exit menu and press <Enter>. - Page 105 Chapter 6: BIOS When the item above -"Boot Mode Select" is set to Legacy, the following items will be display for configuration: • Boot Option #1 - Boot Option #7 When the item above -"Boot Mode Select" is set to UEFI, the following items will be display for configuration: •...
-
Page 106: Save & Exit
SuperServer 1029GQ-T(N/X/V)RT User's Manual 6.8 Save & Exit Use this tab page to configure Save & Exit settings. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Save &... - Page 107 Chapter 6: BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility program. Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter> to load manufacturer default settings which are intended for maximum system performance but not for maximum stability.
-
Page 108: Appendix A Bios Error Codes
When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/. -
Page 109: Appendix B Standardized Warning Statements For Ac Systems
Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/... - Page 110 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
- Page 111 SuperServer 1029GQ-T(N/X/V)RT User's Manual . ٌ ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز ٍ...
- Page 112 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .יש...
- Page 113 SuperServer 1029GQ-T(N/X/V)RT User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
- Page 114 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
- Page 115 SuperServer 1029GQ-T(N/X/V)RT User's Manual يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد انطاقت قبم انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
- Page 116 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !אזהרה .צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד واملدربيه...
- Page 117 SuperServer 1029GQ-T(N/X/V)RT User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
- Page 118 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
- Page 119 SuperServer 1029GQ-T(N/X/V)RT User's Manual هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل اسحبذال البطارية فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
- Page 120 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
- Page 121 SuperServer 1029GQ-T(N/X/V)RT User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
- Page 122 Appendix B: Standardized Warning Statements هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
- Page 123 SuperServer 1029GQ-T(N/X/V)RT User's Manual תיאום חוקי החשמל הארצי !אזהרה .התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة بالكهرباء 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
- Page 124 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. סילוק המוצר !אזהרה .סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה التخلص...
- Page 125 SuperServer 1029GQ-T(N/X/V)RT User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
- Page 126 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
- Page 127 .قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحيUL وأCSA ( ةمالع لمحت يتلاوUL/CSA) لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عمSupermicro.
- Page 128 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
-
Page 129: Appendix C System Specifications
Appendix C: System Specifications Appendix C System Specifications Processors Dual Intel Xeon Scalable-SP and 2nd Gen Intel Xeon Scalable-SP processors in a P (LGA3647) socket, which offer two Intel UltraPath Interconnect (UPI) links of up to 10.4 GT/s; Intel Xeon Scalable-SP processors include 81xx/61xx/51xx/41xx/31xx families, and Intel Xeon 2nd Gen Scalable-SP processors include 82xx/62xx/52xx/42xx/32xx families. - Page 130 SuperServer 1029GQ-T(N/X/V)RT User's Manual Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and DIRECTIVE 2012/19/EU...
-
Page 131: Appendix D Uefi Bios Recovery
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. - Page 132 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
- Page 133 Appendix D: UEFI BIOS Recovery 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
- Page 134 SuperServer 1029GQ-T(N/X/V)RT User Manual 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
- Page 135 Appendix D: UEFI BIOS Recovery 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.
-
Page 136: Appendix E Crash Dump Using Ipmi
In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. For this purpose you can download a crash dump of status information using IPMI. The IPMI manual is available at https://www.supermicro.com/ solutions/IPMI.cfm. - Page 137 Appendix E Crash Dump Using IPMI Downloading the Crash Dump File 1. In the IPMI interface, click the Miscellanous tab, then the Trouble Shooting option. 2. Click the Dump button and wait five minutes for the file to be created. (No confirm ation message will appear.) 3.
-
Page 138: Appendix F Cpu-Based Raid For Nvme
SuperServer 1029GQ-T(N/X/V)RT User's Manual Appendix F CPU-Based RAID for NVMe Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCI-E root complex. Note: The 1029GQ-TNRT model supports VROC in standard configuration. - Page 139 Appendix F CPU-Based RAID for NVMe Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm F.1 Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.
- Page 140 SuperServer 1029GQ-T(N/X/V)RT User's Manual F.2 Enabling NVMe RAID RAID for NVMe SSDs must be enabled through the UEFI BIOS. 1. Install the patch as described in the Restrictions and Requirements section on a previous page. 2. Reboot the server. 3. Press [DEL] key to enter BIOS. 4.
- Page 141 Appendix F CPU-Based RAID for NVMe Figure F-3. Created Volume without Figure F-4. Created Volume with enabling RAID spanned over VMD enabling RAID spanned over VMD controller controller 11. If cross-controller RAID is required, select Enable RAID spanned over VMD Controller as shown in Figure F-4.
- Page 142 SuperServer 1029GQ-T(N/X/V)RT User's Manual F.3 Status Indications An LED indicator on the drive carrier shows the RAID status of the drive. Drive Carrier Status LED Indicator Status State (red) Normal function Locating 4 Hz blink Fault Solid on Rebuilding 1 Hz Blink IBPI SFF 8489 Defined Status LED States F.4 Hot Swap Drives Intel VMD enables hot-plug and hot-unplug for NVMe SSDs, whether from Intel or other...
-
Page 143: Appendix G Bsmi Chinese Safety Warnings
Appendix G BSMI Chinese Safety Warnings Appendix G BSMI Chinese Safety Warnings 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：伺服器/ Server Equipment name , 系列型號: SYS-1029GQ-TRT, SYS-1029GQ-TNRT 型號（型式）：118-20 Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 六價鉻... - Page 144 SuperServer 1029GQ-T(N/X/V)RT User's Manual * 輸入額定 : 100-127V ~, 60-50Hz, 12-9.5A , 200-240V ~, 60-50Hz, 10-9.8A * 使用者不能任意拆除或替換內部配備 * 報驗義務人之姓名或名稱: 美超微電腦股份有限公司 * 報驗義務人之地址: 新北市中和區建一路 150 號 3 樓...
