  • Page 1 SuperServer ® SYS-111AD-WRN2 USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 I f y o u h a v e a n y q u e s t i o n s , p l e a s e c o n t a c t o u r s u p p o r t t e a m a t : support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level.

  • Page 4: Table Of Contents

    Preface Contents Contacting Supermicro ......................7 Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View ...........................9 Control Panel .........................10 Rear View ..........................11 1.3 Motherboard Layout ......................12 Quick Reference Table ......................13 Motherboard Block Diagram .....................15 Chapter 2 Installation 2.1 Overview ..........................16 2.2 Unpacking the System .......................16...
  • Page 5 Preface Installing the LGA1700 Processor ..................26 Installing a CPU Heatsink ....................29 Removing the Heatsink .....................32 3.3 Memory ..........................33 Memory Support ........................33 DIMM Module Population Configuration ................33 General Guidelines for Optimizing Memory Performance ..........33 DIMM Installation ......................34 DIMM Removal .........................34 3.4 Motherboard Battery ......................35 3.5 Storage Drives ........................36 3.6 Installing Expansion Cards ....................38 3.7 System Cooling ........................40...
  • Page 6 7.5 Frequently Asked Questions ....................72 7.6 Returning Merchandise for Service ..................73 7.7 Battery Removal and Installation ..................73 Battery Removal ........................73 Proper Battery Disposal ....................74 Battery Installation ......................74 7.8 Contacting Supermicro .......................75 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...

  • Page 7: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    1.7" x 17.2" x 16.9" (43 x 437 x 429 mm) (H x W x D) Note: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-111AD-WRN2 have been certified as...

  • Page 9: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Fans Control Panel 2.5" Drive Bays Service Tag Figure 1-1. Front View System Features: Front Feature Description Fans...

  • Page 10: Control Panel

    Chapter 1: Introduction Control Panel There are two buttons and several LEDs on the control panel to keep you constantly informed of the overall status of the system as well as the activity and health of specific components. There are also status lights for the power supply. Power Button Information LED Reset Button...

  • Page 11: Rear View

    Chapter 1: Introduction Rear View Expansion Slots Power Supply Rear I/O Backpanel Figure 1-3. System: Rear View Note: AOCs are not included in this system and must be purchased separately. System Features: Rear Feature Description Power Supply One 800 W high-efficiency (Platinum level) power supply Rear I/O Backpanel Rear I/O backpanel (details below) Expansion Slots...

  • Page 12: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the X13SAW-F motherboard with jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4 or the Motherboard Manual.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting (*) JBT1 CMOS Clear Open (Normal) JPF1 POWER FORCE ON Pins 1–2 (Enabled) JPG1 VGA Enable/Disable Pins 1–2 (Enabled) JPME2 ME Manufacturing Mode Pins 1–2 (Normal) JPO1 CPU Throttle when PWR_FAIL Pins 1–2 (Enabled) JPT1 Onboard TPM Module Enable/Disable...
  • Page 14 JSMB1 System Management Bus Header JSXB1A/1B/1C PCIe 5.0 x16 Slots (Supermicro Proprietary WIO Left Add-on Card Slots) JSXB2 PCIe 4.0 x4 (in x16) Slot (Supermicro Proprietary WIO Right Add-on Card Slot) JTPM1 Trusted Platform Module/Port 80 Connector JUIDB1 UID Switch LAN1/2 RJ45 2.5 GbE LAN ports...

  • Page 15: Motherboard Block Diagram

    Chapter 1: Introduction Motherboard Block Diagram PCIe 5.0_x16/ PCIe 5.0 x8+x8 JSXB1 PCIe 5.0 x16 32.0GT/s INTEL LGA1700 DDR5 (CHA) - UDIMM DIMMA1 DIMMA2 4400 MHz- ECC/Non-ECC PCIe 4.0_x4 JMD1 M.2 M-KEY 16.0GT/s DDR5 (CHB) - UDIMM DIMMB1 DIMMB2 4400 MHz- ECC/Non-ECC HBR2 DDIB/DDID DP x2...

  • Page 16: Chapter 2 Installation

    Chapter 2: Installation Chapter 2 Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 3 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 17: Rack Precautions

    Chapter 2: Installation • This product is not suitable for use with visual display workplace devices according to §2 of the German Ordinance for Work with Visual Display Units. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.

  • Page 18: Airflow

    Chapter 2: Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 19: Installing The System Into A Rack

    Chapter 2: Installation 2.4 Installing the System into a Rack This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure differs slightly.

  • Page 20: Assembling The Outer Rails

    Chapter 2: Installation Assembling the Outer Rails Each outer rail comes in two sections that must be assembled before mounting onto the rack. Assembling the Outer Rails 1. Identify the left and right outer rails by examining the ends, which bend outward. Match the left front outer rail with the left rear outer rail and the same for the right rails.

  • Page 21: Installing The Outer Rails Onto The Rack

    Chapter 2: Installation Installing the Outer Rails onto the Rack Each end of the assembled outer rail includes a bracket with square pegs to fit into your rack holes. If you have an older rack with round holes, these brackets must be removed, and you must use screws to secure the rail to the rack.

  • Page 22: Sliding The Chassis Onto The Rack Rails

    Chapter 2: Installation Sliding the Chassis onto the Rack Rails Installing the Chassis into a Rack 1. Align the chassis rails with the front of the rack rails. 2. Slide the chassis rails into the rack rails, keeping the pressure even on both sides. The spring latch engages when the chassis is part way in.

  • Page 23: Installing The Server Into A Two Post (Telco) Rack

    Chapter 2: Installation Installing the Server into a Two Post (Telco) Rack Optional brackets (p/n MCP-290-00016-0N) are needed to install the server to a two post (telco type) rack. Use the two L-shaped brackets on either side of the chassis (four total). 1.

  • Page 24: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 25: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.1 Accessing the System You may need to remove the top cover to access the inside of the system for some of the procedures desccibed in this chapter. Removing the Chassis Top Cover 1. Remove the thumb screw securing the top cover to the chassis. 2.

  • Page 26: Processor And Heatsink Installation

    Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustrations only. Your components may look different.
  • Page 27 Chapter 3: Maintenance and Component Installation 2. Gently push down the load lever to release and lift it, then lift the load plate to open it completely. Lever lock 3. Use your thumb and your index finger to hold the CPU. Align the small triangle maker and notches on the CPU to the corresponding triangle maker and notches on the CPU load bracket.
  • Page 28 Chapter 3: Maintenance and Component Installation 6. Close the load plate with the CPU inside the socket. Gently push the load lever down to the lever locks. Lever lock Important: You can only install the CPU inside the socket in one direction. Make sure that it is properly inserted into the CPU socket before closing the load plate.

  • Page 29: Installing A Cpu Heatsink

    Chapter 3: Maintenance and Component Installation Installing a CPU Heatsink Note 1: The installation described in this section is for reference only. The actual in- stallation steps may vary depending on the CPU heatsink model. Please refer to the heatsink instruction for more details. Note 2: Graphic drawings included in this manual are for reference only.
  • Page 30 Chapter 3: Maintenance and Component Installation 3. Attach the backplate into the mounting holes around the CPU socket on the bottom side of the motherboard. Backplate bottom side Motherboard bottom side Mounting hole Motherboard Top side...
  • Page 31 Chapter 3: Maintenance and Component Installation 4. Apply the proper amount of thermal grease on the CPU. 5. Place the heatsink on top of the CPU so that the four mounting holes on the heatsink are aligned with those on the retention mechanism. 6.

  • Page 32: Removing The Heatsink

    Chapter 3: Maintenance and Component Installation Removing the Heatsink Warning: We do not recommend that the CPU or heatsink be removed. However, if you do need to remove the heatsink, please follow the instructions below to uninstall it to avoid damaging the CPU or other components.

  • Page 33: Memory

    Chapter 3: Maintenance and Component Installation 3.3 Memory Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X13SAW-F supports up to 128 GB of DDR5 ECC/Non-ECC/ECC UDIMM memory with speeds of up to 4400 MT/s in four memory slots.

  • Page 34: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Insert the desired number of DIMMs into the memory slots. See Memory Support for details on memory population guidelines. Receptive Point 2. Push the release tabs outwards on both ends of the DIMM slot to unlock it. 3.

  • Page 35: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.4 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery 1. Push aside the small clamp that covers the edge of the battery. When the battery is released, lift it out of the holder.

  • Page 36: Storage Drives

    Chapter 3: Maintenance and Component Installation 3.5 Storage Drives The system supports two fixed 2.5" storage drives. Note: Enterprise level hard disk drives are recommended for use in Supermicro servers. For information on recommended HDDs, visit the Supermicro website at https://www.supermicro.com/en/about/sitemap.
  • Page 37 Chapter 3: Maintenance and Component Installation Figure 3-5. Installing 2.5" Storage Drives in the System Note: AOCs are not included in this system and must be purchased separately.

  • Page 38: Installing Expansion Cards

    Chapter 3: Maintenance and Component Installation 3.6 Installing Expansion Cards The system supports two full-height, full-length and one low-profile PCIe expansion cards. Expansion cards are installed using a riser card (RSC-W-68G5 and RSC-WR-6) and a riser bracket. Figure 3-6. Removing the Riser Card Bracket Note: AOCs are not included in this system and must be purchased separately.
  • Page 39 Chapter 3: Maintenance and Component Installation 5. Install the expansion card into the riser card slot. 6. Install the bracket into the slot on the serverboard while aligning the bracket in the rear of the chassis. Figure 3-7. Installing the Riser Card Bracket Note: AOCs are not included in this system and must be purchased separately.

  • Page 40: System Cooling

    Chapter 3: Maintenance and Component Installation 3.7 System Cooling The CSE-514-R00RWNP chassis includes five heavy-duty, counter-rotating fans for system cooling. Replacing a System Fan 1. If necessary, open the chassis cover while the power is running to determine which fan requires changing.
  • Page 41 Chapter 3: Maintenance and Component Installation Figure 3-8. Installing a Fan Figure 3-9. Removing a Fan from the Fan Housing...

  • Page 42: Installing The Air Shroud

    Chapter 3: Maintenance and Component Installation Replacing the Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. The air shroud in the SYS-111AD-WRN2 does not require screws to install. 1. Power down the system and remove the top cover. 2.

  • Page 43: Power Supply

    100 V to 240 V input voltage. It is necessary to shut down the system when changing the power supply. If replacing, use the exact same model. New units can be ordered directly from Supermicro or authorized distributors.
  • Page 44 Chapter 3: Maintenance and Component Installation 2. Power down the system and remove the power cord from the power supply module. 3. Push the release latch on the power supply towards the handle. 4. Using the handle, pull the power supply out of the chassis. 5.

  • Page 45: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections JTPM1 Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. JPO1 Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. The motherboard layout indicating component locations may be found in Chapter JMD1...

  • Page 46: Headers And Connectors

    Chapter 4: Motherboard Connections 4-pin HDD Power Connector JPH1 is a 4-pin power connector that provides power to onboard HDD devices. Refer to the table below for pin definitions. 4-pin HDD Power Pin Definitions Pin# Definition JPH1 12 V 4.2 Headers and Connectors Fan Headers There are six 4-pin fan headers on the motherboard.
  • Page 47 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
  • Page 48 2280 and 22110 form factors. JMD2 supports a PCIe 3.0 x4 device in the 2280 form factor. COM Headers The motherboard has one COM header (COM1) that provides serial connections, utilizing Supermicro PN: CBL-CDAT-0604 or CBL-CUSB-0984 (not included). COM1 supports RS- 232/422/485. COM Header Pin Definitions...
  • Page 49 Chapter 4: Motherboard Connections MCIO Connector The motherboard supports a PCIe 4.0 x4 NVMe connection. This connector provides high- speed and low-latency connections directly from the CPU to NVMe Solid State (SSD) drives. This greatly increases SSD data-throughput performance and significantly reduces PCIe latency by simplifying driver/software requirements resulting from direct PCIe interface from the CPU to the NVMe SSD drives.

  • Page 50: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the location of JF1. Ground...
  • Page 51 Chapter 4: Motherboard Connections Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections. The LED on pin 8 provides warnings of overheating or fan failure. Refer to the tables below for pin definitions.

  • Page 52: Input/Output Ports

    Chapter 4: Motherboard Connections NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions. NMI Button Pin Definitions Pins Definition Control Ground 4.3 Input/Output Ports Rear I/O Ports See Figure 4-2 below for the locations and descriptions of the various I/O ports on the rear of the motherboard.
  • Page 53 Chapter 4: Motherboard Connections LAN Ports Two 2.5 GbE Ethernet ports (LAN1–LAN2) are located on the I/O back panel. In addition to the LAN ports, the X13SAW-F motherboard has a dedicated BMC LAN port. All these ports accept RJ45 cables. Please refer to the LED Indicator section for LAN LED information. LAN1/LAN2 BMC LAN Pin Definition...
  • Page 54 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www. supermicro.com/support/manuals/. UID Switch UID LED Pin Definitions...

  • Page 55: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 56 Chapter 4: Motherboard Connections Watchdog Timer Watchdog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1–2 to reset the system if an application hangs. Close pins 2–3 to generate a non-maskable interrupt (NMI) signal for the application that hangs. Refer to the table below for jumper settings.
  • Page 57 Chapter 4: Motherboard Connections PCIe Bifurcation Use JRF1 and JRF2 to adjust the PCIe lane options on the SXB1 expansion slots. The options are x16 and 2x8. PCIe Bifurcation Jumper Settings JRF1 JRF2 Pins 1–2 Pins 1–2 x16 (Default) Pins 2–3 Pins 1–2 ME Manufacturing Mode Close pins 2–3 of jumper JPME2 to bypass SPI flash security and force the system to operate...

  • Page 58: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN LEDs Four LAN ports (LAN1–LAN4) are located on the rear I/O panel of the motherboard. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.
  • Page 59 Chapter 4: Motherboard Connections Onboard Power LED LED3 is the onboard Power LED. When this LED is on, the system is on. Turn off the system and unplug the power cord before removing or installing components. Refer to the table below for more information.

  • Page 60: Chapter 5 Software

    1. Create a method to access the Microsoft Windows installation ISO file. That can be a USB flash or media drive. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 61 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 62: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or media drive.

  • Page 63: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 64: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes alternate configurations and optional system components. Optional Parts List Description Part Number 1U Redundant 800/860 W Titanium AC power supply PWS-862A-1R 6.1 Redundant Power Supply An additional 800/860 W power supply module may be added to the system to provide power redundancy.

  • Page 65: Chapter 7 Troubleshooting And Support

    Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, www.supermicro.com. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the menu icon, then selecting the Products option.

  • Page 66: Baseboard Management Controller (Bmc)

    Security Center for recent security notices Supermicro Phone and Addresses 7.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring, and management. There are several BIOS settings that are related to BMC.

  • Page 67: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/ or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any non hot-swap hardware components.

  • Page 68: No Video

    Chapter 7: Troubleshooting and Support No Video 1. Check that the VGA cable is connected properly, and the monitor is on. 2. Check if you followed the guidelines to install the memory module (see Section 3.4). 3. Reseat the memory DIMM module. Note: If you are a system integrator, VAR or OEM, a POST diagnostics card is recommended.

  • Page 69: When The System Becomes Unstable

    2. Memory support: Make sure that the memory modules are supported by testing the modules using memtest86 or a similar utility. Note: Refer to the product page on our website at http://www.supermicro.com for memory and CPU support and updates. 3. Storage drive support: Make sure that all storage drives work properly. Replace the bad storage drives with good ones.
  • Page 70 Chapter 7: Troubleshooting and Support 6. To find out if a component is good, swap this component with a new one to see if the system will work properly. If so, then the old component is bad. You can also install the component in question in another system.

  • Page 71: Technical Support Procedures

    Chapter 7: Troubleshooting and Support 7.4 Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, note that as a motherboard manufacturer, we do not sell directly to end-users, so it is best to first check with your distributor or reseller for troubleshooting services. They should know of any possible problem(s) with the specific system configuration that was sold to you.

  • Page 72: Frequently Asked Questions

    FLASH.nsh BIOSname#.### <ENTER> Note: Supermicro no longer supports the BIOS update method in DOS. 6. Perform an A/C power cycle after the message indicating the BIOS update has completed. You may refer to the “Readme” file in BIOS package for more details.

  • Page 73: Returning Merchandise For Service

    Shipping and handling charges will be applied for all orders that must be mailed when service is complete. For faster service, RMA authorizations may be requested online (http://www.supermicro.com/ support/rma/). This warranty only covers normal consumer use and does not cover damages incurred in shipping or from failure due to the alteration, misuse, abuse or improper maintenance of products.

  • Page 74: Proper Battery Disposal

    Chapter 7: Troubleshooting and Support Proper Battery Disposal Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 75: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 76: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 77 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 78 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 79 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 80 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 81 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
  • Page 82 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 83 Appendix A: Warning Statements Attention Seul le personnel autorisé et le personnel de maintenance qualifié doivent être autorisés à installer, remplacer ou entretenir cet équipement.. !‫אזהרה‬ ‫.יש לאפשר רק צוות מורשה ואנשי שירות מוסמכים להתקין, להחליף או לטפל בציוד זה‬ ‫.ينبغي...
  • Page 84 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 85 Appendix A: Warning Statements Battery Handling CAUTION: There is risk of explosion if the battery is replaced by an incorrect type. Replace the battery only with the same or equivalent type recommended by the manu- facturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 86 Appendix A: Warning Statements ‫.هناك خطر االنفجار إذا تم استبدال البطارية بنوع غري صحيح‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리를 잘못된 종류로 교체하면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조 사에서...
  • Page 87 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 88 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 89 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 90 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 91 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 92 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 93 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 94 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 95 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 96: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processor Support Single LGA 1700 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 Processor Chipset Intel R680E chipset BIOS 512 Mb AMI BIOS® SPI Flash BIOS ACPI 6.0, Plug and Play (PnP), SPI dual/quad speed support, and Real Time Clock (RTC) wake up Memory Up to 128 GB ECC/non-ECC DDR5 UDIMM memory in four DIMM slots Storage Drives...
  • Page 97 Appendix B: System Specifications Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) CLASS A Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 35 BS/EN 61000-3-2 BS/EN 61000-3-3 BS/EN 61000-4-2 BS/EN 61000-4-3 BS/EN 61000-4-4...
