SuperServer SYS-122H-TN: Motherboard Connections, Jumpers, and LEDs
Fail LED (Information LED) (OH/Fan Fail/PWR Fail)
Status
Solid red (on)
Blinking red (1 Hz)
Blinking red (0.25 Hz)
Blinking red (10 Hz) (FP red LED)
Solid blue
Blinking blue (1 Hz)
BIOS/BMC blinking blue (10 Hz)
Red Info LED blinking (10 Hz) and
MB UID LED blue blinking (10 Hz)

LAN1/LAN2 (NIC1/NIC2)

The NIC (Network Interface Controller) LED connection for LAN Port 1 is located on pin 6 of
JFP1 on the X14DBM-SP motherboard, and LAN Port 2 is on pin 5.
For a detailed diagram of the X14DBM-SP motherboard, see the layout under
Quick Reference" on page

Storage Drive Activity LED

The storage drive activity LED connection is located on pin 7 of JFP1 on the X14DBM-SP
motherboard. When this LED is blinking green, it indicates storage drive activity.
For a detailed diagram of the X14DBM-SP motherboard, see the layout under
Quick Reference" on page
LED States
An overheating has occurred.
Fan failure: check for an inoperative fan.
Power failure: check for a non-operational power supply
CPLD recovery mode error(s)
UID has been activated locally. Use this function to locate a
unit in the system that might be in need of service.
Local UID has been activated locally on. Use this function to
identify a unit that might be in need of service.
BIOS/BMC: recovery and/or update in progress
CPLD: recovery and/or update in progress
27.
LAN1/LAN2 LED
LED States
Color
NIC 2: Blinking green
NIC 1: Blinking green
27.
Storage Drive Activity LED
LED State
Color
Blinking Green Storage Drive Activity
105
Description
State
LAN 2: Active
LAN 1: Active
State
"Motherboard
"Motherboard
