SuperServer SYS-122H-TN: Motherboard Connections, Jumpers, and LEDs
Warning! To avoid damaging the power supply or the motherboard, be sure to use a
power supply that accommodates two power supply units. Be sure to also connect
the power supplies to four 8-pin +12 V power connectors (JPMW1–JPMW4), three
16-pin +12 V power connectors (PMW5–JPMW7), and two 6-pin power connectors
(JPWR1/JPWR2) on the motherboard. Failure in doing so may void the manufacturer
warranty on your power supply and motherboard.
It is strongly recommended that you use a high quality power supply that meets ATX power
supply specification 2.02 or above. It must also be SSI compliant.
Note: The tables below represent the power supplies that support the main power supply
units (PSU1/PSU2) in the Supermicro Hyper and Hyper-E servers. For detailed power
supply support for your particular server, refer to your Hyper Server user manual.
For Hyper Systems:
l
PWS-2K07A-1R
PWS-1K63A-1R
PWS-2K63A-1R
PWS-1K24A-1R
