Supermicro SuperServer SYS-122H-TN User Manual page 47

3.2 Accessing the System
The CSE-HS119-R000NP2 chassis features a removable top cover, which allows easy access
to the inside of the chassis.
Removing the Top Cover
1. Press the release button and slide the cover toward the rear.
2. Lift the top cover up.
Check that all ventilation openings on the top cover and the top of the chassis are clear and
unobstructed.
Warning! Except for short periods of time, do not operate the server without the
cover in place. The chassis cover must be in place to allow for proper airflow and to
prevent overheating.
SuperServer SYS-122H-TN: Maintenance and Component Installation
Figure 3-1. Removing the Chassis Cover
47
