Connector
JPCIE5 (P2_PE0 0–
15)
JPCIE6A1 (P2_PE2 0–
7)
JPCIE6B1 (P2_PE2 8–
15)
JPMW1–JPMW4
JPMW5–JPMW7
JPWR1–JPWR2
PSU1/PSU2
JNCSI
JNVI2C1
JNVVPP1
JTPM1
M.2-C1/M.2-C2
P0_NVME 0
(P1_PE4 0–7)
P0_NVME1
(P1_PE4 8–15)
P0_NVME2
(P1_PE5 0–7)
P0_NVME3
(P1_PE5 8–15)
P1_NVME0
(P2_PE4 0–7)
(P2 SLOT2) PCIe 5.0 x16 slot supported by CPU2
MCIO (P2) PCIe 5.0 x8 connector supported by CPU2
MCIO (P2) PCIe 5.0 x8 connector supported by CPU2
8-pin +12 V power connectors used for system backplane/GPU devices (via
cables)
16-pin +12 V power connectors used for system backplane/GPG devices
(via cables)
6-pin +12 V power connectors for riser card use
Power Supply Unit1/Unit2 for system power use (for 1U systems) (see the
first note)
NC-SI (Network Controller Sideband Interface) connector (see the second
note)
NVMe SMBus I²C header used for PCIe SMBus clock and data connections
with hot-plug support
NVMe VPP SMBus (System Management Bus) with hot-plug support
Trusted Platform Module/Port 80 connector
M.2 M-Key PCIe 5.0 x2 slots (2280/22110)
MCIO P1_PCIe 5.0 x8 connectors supported by CPU1 with NVMe Con-
nections 0–7
MCIO P1_PCIe 5.0 x8 connectors supported by CPU1 with NVMe Con-
nections 8–15
MCIO P1_PCIe 5.0 x8 connectors supported by CPU1 with NVMe Con-
nections 0–7
MCIO P1_PCIe 5.0 x8 connectors supported by CPU1 with NVMe Con-
nections 8–15
MCIO P2_PCIe 5.0 x8 connectors supported by CPU2 with NVMe Con-
nections 0–7
30
SuperServer SYS-122H-TN: Introduction
Description
