SIMM Removal

Remove any optional SIMM sticks from the system board as follows.
1. Remove the side panel and any full size expansion boards as previously described.
Open the clips at each end of the SIMM connector (see Figure Section 5-4). Tilt
2.
the SIMM forward, so that the SIMM can be removed from the socket.
Remove the SIMM stick from the system board. Repeat steps 2 and 3 for each
3.
SIMM being removed.
Hole
Post
NOTE: For information on installing SIMM
sticks is in Section 3, "Options".
Figure Section 5-4 SIMM Socket
Repair
Clips
5-5
