1-10 Technical Information
SIMMs install directly in the four sockets on the system board. The four sockets are
assigned as Bank 0 (2 sockets) and Bank 1 (2 sockets).
All configurations have two 8 MB SIMMs are installed in bank 0. SIMMs must be installed
in pairs of the same memory type. Both sockets must be populated within a bank for the
system to work. No switch or jumpers are required to set when the memory is changed. The
system BIOS automatically detects the SIMMs. Table 1-4 shows the SIMM memory
upgrade path.
Total Memory
16 MB*
24 MB
24 MB
32 MB
32 MB
40 MB
40 MB
48 MB
48 MB
64 MB
64 MB
72 MB
72 MB
80 MB
80 MB
96 MB
96 MB
128 MB
* Standard configuration.
CAUTION: SIMMs must match the tin metal
plating used on the system board SIMM sockets.
When adding SIMMs, use tin-plated SIMMs.
Table 1-4 SIMM Memory Upgrade Path
Bank 0
8 MB
4 MB
8 MB
8 MB
16 MB
4 MB
16 MB
8 MB
16 MB
16 MB
32 MB
4 MB
32 MB
8 MB
32 MB
16 MB
32 MB
32 MB
Bank 0 Bank 1
8 MB Empty
4 MB 8 MB
8 MB 4 MB
8 MB 8 MB
16 MB Empty
4 MB 16 MB
16 MB 4 MB
8 MB 16 MB
16 MB 8 MB
16 MB 16 MB
32 MB Empty
4 MB 32 MB
32 MB 4 MB
8 MB 32 MB
32 MB 8 MB
16 MB 32 MB
32 MB 16 MB
32 MB 32 MB
Bank 1
Empty
8 MB
4 MB
8 MB
Empty
16 MB
4 MB
16 MB
8 MB
16 MB
Empty
32 MB
4 MB
32 MB
8 MB
32 MB
16 MB
32 MB
