FAN CONNECTOR

The following figure shows the fan connector on the system board. Table Appendix A-24
provides the pin assignments.
Pin
10
11
12
Figure Appendix A-12 Fan Connector
Table Appendix A-24 Fan Pin Assignments
Signal Name
Ground
+12 V (fused)
Ground
Connector Pin Assignments
A-13
