5-16 Repair

Illustrated Parts Breakdown

This subsection contains the illustrated parts breakdown (IPB) and NEC part numbers for
the PowerMate P Series computer. Table Section 5-2 lists the field-replaceable parts for the
computer. Figure Section 5-28 is the illustrated parts breakdown.
Table Section 5-2 PowerMate P Series Field-Replaceable Parts List*
Item Description
1 Front Panel Bezel (with lamps and power button)
2 IR Card with Cable
3 IR to 5 Connector Cable
4 Speaker Assembly
5 Card Guide/Fan Bracket (metal)
6 Card Guide/Fan Cover (plastic)
7 Fan Assembly
8 8-MB SIMM, 32-bits
9A Pentium 120/60 CPU with heatsink (VR voltage)
9B Pentium 133/66 CPU with heatsink (VR voltage)
10 Heatsink Clip
11 Battery
12A System Board with Audio (multimedia)
12B System Board without Audio (nonmultimedia)
13 Side Panel
14 Power Supply (200W)
15 Video Riser Card
16 Audio Riser Card
17 Diskette Drive Signal Cable
18 Microphone
19 Serial COM Cable, Internal (2)
____________
*This data was prepared September 1995. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476
and order document number 42181365.
NOTE: In the U.S., call 1(800) 632-4525 to
order NEC spare parts. To order options in the
U.S., call the local NEC sales office. See Table
5-1 in Section 5 for NEC telephone numbers.
Part Number
158-050910-000
158-050909-000
158-050911-000
158-050945-000
158-030849-000
158-030850-000
158-050944-000
158-082553-070
158-050924-009
158-050924-001
158-060368-000
158-056137-000
158-050886-001A
158-050886-000A
158-050916-000
158-050888-000
158-050917-000
158-050923-000
158-050920-000
158-050878-000
158-050918-000
