Blank Panel and Metal Cover Plate Removal

Remove the blank panels and the metal cover plates from the chassis as follows.
1. Remove the blank panel from the selected slot by pressing the panel tabs from
inside the front panel and pushing the blank panel out (see Figure Section 5-7).
Store the blank panel for possible later reinstallation.
Press in on the tab and remove the metal slot cover from the selected slot on the
2.
front of the system.
Store the slot cover in case you choose to use it in the future.
Slot Cover
Blank Panel
Tabs
Slot Cover
Tab
Figure Section 5-7 Removing the Blank Panels
Repair 5-7
